Page 9: About This Manual
The purpose of this manual is to present the descriptions and drawings required to do basic maintenance tasks on the EM 712 Multibeam echo sounder . The equipment described in this manual includes the complete system with associated cabinets, but not those system units provided locally by the customer, installation shipyard or local dealer.
Page 10: Kongsberg Em 712
Kongsberg EM 712 Maintenance Manual Kongsberg EM 712 Topics System description, page 11 EM 712B, upgrade from EM 710, page 11 System diagram - 0.25° x 0.5° system, page 12 System units, page 14 451106/B...
Page 11: System Description
3 m below its transducers, and the maximum acquisition depth is up to 3600 m. The EM 712 replaces the EM 710. EM 712 is built with new, state of the art technology. By increasing the frequency range from 70-100 kHz to 40-100 kHz, the range performance is greatly improved.
Page 12: System Diagram - 0.25° X 0.5° System
Kongsberg EM 712 Maintenance Manual System diagram - 0.25° x 0.5° system The system diagram identifies the main components of a basic EM 712 system. Only the main connections between the units are shown. Detailed interface capabilities and power cables are not shown.
Page 13 Kongsberg EM 712 Interfaces: • Sound speed sensor • Tide • Centre depth output Processing Unit Interfaces: • Positioning systems • Attitude (roll, pitch and heave) • Sound speed sensor – With K-Controller upgrade • Velocity • Heading • Clock •...
Page 14: System Units
Both transducer arrays should be horizontal on a plane on the keel. Processing Unit description The EM 712 Processing Unit is provided to process the signals to and from the Transmitter and Receiver Units. The EM 712 Processing Unit is an industrial computer using both COTS (commercial off-the-shelf) components and custom made components.
Page 15: Transmitter Unit Description
The unit can also be placed in the "survey room" or on the bridge. Transmitter Unit description The EM 712 Transmitter Unit has all transmit electronics, like control processors, power amplifiers, power supply, capacitor battery and Ethernet interface. The Transmitter Unit is a wall-mounted steel cabinet with integrated shock and vibration absorbers, designed for bulkhead mounting.
Page 16: Receiver Unit Description
Kongsberg EM 712 Maintenance Manual Receiver Unit description The EM 712 Receiver Unit has all receive electronics, like control processor, amplifiers, Analog-to-Digital Converters, power supply and Ethernet interface. The Receiver Unit is a small wall-mounted steel cabinet with integrated shock and vibration absorbers, designed for bulkhead mounting.
Page 17: Troubleshooting
Troubleshooting Troubleshooting Topics Tools for troubleshooting, page 18 BIST (Built-In Self Test) dialog box, page 19 BIST (Built-In Self Test) theory, page 22 451106/B...
Page 18: Tools For Troubleshooting
However, key components that fail will in most cases be detected by the tools you have available. The most important tool is your own knowledge about the EM 712. Based on a list of the main components in the system, brief descriptions of what they do and how they work, including suggested certain symptoms, you may work out the possible solutions.
Page 19: Bist (Built-In Self Test) Dialog Box
Troubleshooting BIST (Built-In Self Test) dialog box dialog box provides several automatic tests to check the operation of the BIST echo sounder system. How to open • : Select on the menu. Select the Installation Parameters View Installation icon and select Parameters BIST •...
Page 20 Kongsberg EM 712 Maintenance Manual Details CPU Test This test presents the CPU type, the CPU clock frequency, the current and maximum temperatures for the CPU die and for the CPU board. In addition some key voltages are reported, and finally the network addresses for the board’s interfaces.
Page 21 Troubleshooting RX noise level This test measures the average isotropic spectral noise level for each receiver channel (in dB rel 1 μPa/Hz) for different frequency bands. The receiver directivity index, the transducer sensitivity and the filter bandwidth is used to convert to isotropic spectral noise level.
Page 22: Bist (Built-In Self Test) Theory
Kongsberg EM 712 Maintenance Manual BIST (Built-In Self Test) theory Topics BIST Introduction, page 23 CPU Test, page 24 CBMF test, page 25 RX unit test, page 26 TX unit test, page 27 CBMF-CPU link, page 28 RX-CBMF link, page 29...
Page 23: Bist Introduction
Troubleshooting BIST Introduction The purpose of the offline BIST system is to detect errors and locate the failed module. The BIST tests are organized in a sequence, and tests module by module. The CPU executes the BISTs and sends the BIST reply to the operator station. Temperature, voltage, communication and firmware versions of each board and module are tested.
Page 24: Cpu Test
Kongsberg EM 712 Maintenance Manual CPU Test Checks the CPU board in the in the EM 712 Processing Unit. This test presents the CPU type, the CPU clock frequency, the current and maximum temperatures for the CPU die and for the CPU board. Checks all beamformer and signal processing boards (CBMF) in the EM 712 Processing Unit.
Page 25: Cbmf Test
Troubleshooting CBMF test Checks all beamformer and signal processing boards (CBMF) in the EM 712 Processing Unit. This test presents the CBMF board temperature, the internal power supply voltages. In addition software and firmware versions are displayed. Dark green modules are to be tested. Light green modules have to function to be able to perform current test.
Page 26: Rx Unit Test
Kongsberg EM 712 Maintenance Manual RX unit test Checks the receiver electronics in the EM 712 Receiver Unit. This test presents the internal temperatures and voltages in the receiver electronics. In addition software and firmware versions are displayed. Dark green modules are to be tested. Light green modules have to function to be able to perform current test.
Page 27: Tx Unit Test
Troubleshooting TX unit test Checks the transmitter electronics in the EM 712 Transmitter Unit. This test presents the internal temperatures and voltages in the transmitter electronics. In addition software and firmware versions are displayed. Dark green modules are to be tested. Light green modules have to function to be able to perform current test.
Page 28: Cbmf-Cpu Link
Kongsberg EM 712 Maintenance Manual CBMF-CPU link Checks the parallel bus interface between the CBMF board and the CPU board. This test checks CBMF board(s), Ethernet connection and the parallel bus interface between the CBMF board(s) and the CPU circuit board. A large set of known data is transferred from the CPU unit on Ethernet via CBMF back to the CPU board.
Page 29: Rx-Cbmf Link
Troubleshooting RX-CBMF link This test checks the GBit interface between the RX unit and the CBMF boards. A large set of known data is transferred from RX unit via CBMF to the CPU board on parallel bus. The data received is checked by the CPU board. Dark green modules are to be tested.
Page 30: Rx Channels
Kongsberg EM 712 Maintenance Manual RX channels Checks the RX channels including transducers by injecting a test signal at receiver input. • EM 712 The Receiver Unit has a programmable signal generator board that is used to inject a test signal at the preamplifier inputs in the RX arrays. The BIST report displays the measured RX transducer impedance for all RX channels.
Page 31: Tx Channels
Troubleshooting TX channels Checks all TX channels including the transducers. This test checks the impedance of all TX elements. This is done by measuring the voltage and current used by all individual transmitters. Dark green modules are to be tested. Light green modules have to function to be able to perform current test.
Page 32: Rx Noise Level
Kongsberg EM 712 Maintenance Manual RX noise level Checks the isotropic spectral noise level. This test measures the average isotropic spectral noise level for each receiver channel (in dB rel 1 μPa/Hz) for different frequency bands. The receiver directivity index, the transducer sensitivity and the filter bandwidth is used to convert to isotropic spectral noise level.
Page 33: Rx Noise Spectrum
Troubleshooting RX noise spectrum Checks the isotropic spectral noise level. This test measures the isotropic spectral noise level for each receiver channel as done in the RX noise level test. The noise spectrum level is displayed for small frequency bands for groups of 32 channels.
Page 34: Software Date And Versions
Generates a status report for the EM 712 system. This test acquires information needed (serial numbers, software versions, BIST results etc.) for a status report. This report can be sent to the factory to update the EM 712 product database.
Page 35: Preventive Maintenance
Preventive maintenance Preventive maintenance Topics Inspecting and cleaning the transducer face, page 36 Painting the transducer face, page 38 Inspecting and replacing sacrificial anodes, page 40 Approved anti-fouling paints, page 41 451106/B...
Page 36: Inspecting And Cleaning The Transducer Face
Context During normal use, the transducer is subjected to biological fouling. If this marine growth is excessive, it will reduce the performance of the EM 712. Whenever opportunity arise, typically when the vessel is dry-docked, the transducer face must be cleaned for shells and other marine growth.
Page 37 Apply anti-fouling paint as described in the dedicated procedure. Note Because some paint types may be aggressive to the polyurethane in the transducer, consult our list of approved paints. The list can also be found on Kongsberg Maritime (https://www.kongs- berg.com/maritime/). 451106/B...
Page 38: Painting The Transducer Face
Kongsberg EM 712 Maintenance Manual Painting the transducer face Marine growth (biological fouling) on the transducer face reduces the EM 712 performance. We recommend that you paint the transducer face immediately after installation, and then again as often as required to maintain the protection.
Page 39 Abrade the transducer surface using a sanding paper with 240 inch grit size. Do not exceed a surface roughness (R ) of 35 microns as this can influence the EM 712 performance. Remove all dust. Apply the primer, and let it dry.
Page 40: Inspecting And Replacing Sacrificial Anodes
Kongsberg EM 712 Maintenance Manual Inspecting and replacing sacrificial anodes Anodes are used on various units to prevent metals from corroding in salt water. Context Anodes are constructed of a metal alloy with an active voltage that is greater than the metal of the structure;...
Page 41: Approved Anti-Fouling Paints
Preventive maintenance Approved anti-fouling paints This is our list of approved antifouling paints for all transducer types. Always refer to the manufacturer's documentation and data sheets for a complete procedure and for relevant safety information. Important Do not paint the transducer with traditional hull plating paint. Use only the correct type of approved paint specified.
Page 42 Apply 150 µm dry film thickness. • Intersmooth 7465Si SPC – : Intergard 269 Primer Apply 40 µm dry film thickness. – : Intersmooth 7465Si SPC Paint Apply 100 µm dry film thickness. The list can also be found on Kongsberg Maritime (https://www.kongsberg.com/mar- itime/). 451106/B...
Page 43: Parts Replacement
Parts replacement Parts replacement Topics Tools and equipment required for parts replacement, page 44 Processing Unit replacement, page 46 CPU board replacement, page 49 VadaTech CP219 Ethernet switch replacement, page 52 CBMF board replacement, page 55 Fan unit replacement, page 58 Processing Unit fuse replacement, page 61 451106/B...
Page 44: Tools And Equipment Required For Parts Replacement
Kongsberg EM 712 Maintenance Manual Tools and equipment required for parts replacement In order to safely remove and replace printed circuit boards modules, generic and specific tools are required. You must be equipped with a standard set of tools. This tool set must comprise the normal tools for electronic and electromechanical tasks.
Page 45 Parts replacement If, for any reason, it is necessary to move the circuit board from the conductive service mat, it must be placed in an approved antistatic transportation container (for example a static shielding bag) before transportation. During installation and servicing, all electrical equipment (for example soldering irons and test equipment) must be earthed.
Page 46: Processing Unit Replacement
Kongsberg EM 712 Maintenance Manual Processing Unit replacement If a Processing Unit fails to operate, it must be replaced with a new unit. All replacement tasks must be done according to the specified procedures, and you must follow the relevant safety instructions.
Page 47: Removing The Processing Unit
Parts replacement Removing the Processing Unit One or two Processing Units are used in the EM 712 system. The complete Processing Unit can be supplied as a spare part. Prerequisites You must be equipped with a standard set of tools. This tool set must comprise the normal tools for mechanical tasks.
Page 48: Installing The Processing Unit
When you connect the cables, make sure that they are all properly secured, and able to withstand the vibration and movements of the vessel. Further requirements Once the unit has been installed, follow the normal procedure to turn on the EM 712. 451106/B...
Page 49: Cpu Board Replacement
This is a generic photo. The CPU board used by the EM 712 may look slightly different due to minor design changes on the protective lid and/or the front panel.
Page 50: Removing The Cpu Board
Prerequisites This is a generic photo. The CPU board used by the EM 712 may look slightly different due to minor design changes on the protective lid and/or the front panel. You must be equipped with a standard set of tools. This tool set must comprise the normal tools for electromechanical tasks.
Page 51: Installing The Cpu Board
Prerequisites This is a generic photo. The CPU board used by the EM 712 may look slightly different due to minor design changes on the protective lid and/or the front panel. A new circuit board must be available.
Page 52: Vadatech Cp219 Ethernet Switch Replacement
All replacement tasks must be done according to the specified procedures, and you must follow the relevant safety instructions. The VadaTech CP219 board is used as an Ethernet switch in the EM 712 Processing Unit. Note These procedures will instruct you to handle electronic circuit boards and/or modules.
Page 53: Removing The Vadatech Cp219 Ethernet Switch
Parts replacement Removing the VadaTech CP219 Ethernet switch If a VadaTech CP219 Ethernet switch fails to operate, it must be replaced with a new switch. All replacement tasks must be done according to the specified procedures, and you must follow the relevant safety instructions. Prerequisites You must be equipped with a standard set of tools.
Page 54: Installing The Vadatech Cp219 Ethernet Switch
Kongsberg EM 712 Maintenance Manual Installing the VadaTech CP219 Ethernet switch If a VadaTech CP219 Ethernet switch fails to operate, it must be replaced with a new switch. All replacement tasks must be done according to the specified procedures, and you must follow the relevant safety instructions.
Page 55: Cbmf Board Replacement
Parts replacement CBMF board replacement If a CBMF board fails to operate, it must be replaced with a new circuit board. All replacement tasks must be done according to the specified procedures, and you must follow the relevant safety instructions. The Compact Beamformer (CBMF) board is used by the Processing Unit for beamforming and signal processing purposes.
Page 56: Removing The Cbmf Board
Prerequisites This is a generic photo. The CBMF board used by the EM 712 may look slightly different due to minor design changes on the protective lid and/or the front panel. You must be equipped with a standard set of tools. This tool set must comprise the normal tools for electromechanical tasks.
Page 57: Installing The Cbmf Board
Prerequisites This is a generic photo. The CBMF board used by the EM 712 may look slightly different due to minor design changes on the protective lid and/or the front panel. You must be equipped with a standard set of tools. This tool set must comprise the normal tools for electromechanical tasks.
Page 58: Fan Unit Replacement
Kongsberg EM 712 Maintenance Manual Fan unit replacement If a fan unit fails to operate, it must be replaced with a new module. All replacement tasks must be done according to the specified procedures, and you must follow the relevant safety instructions.
Page 59: Removing The Fan Unit
Parts replacement Removing the fan unit If a fan unit fails to operate, it must be replaced with a new module. All replacement tasks must be done according to the specified procedures, and you must follow the relevant safety instructions. Prerequisites You must be equipped with a standard set of tools.
Page 60: Installing The Fan Unit
Make sure that all AC mains power has been disconnected. Grab the handle and push the unit straight in. Tighten the screw. Connect AC mains power. Further requirements Once the unit has been installed, follow the normal procedure to turn on the EM 712. 451106/B...
Page 61: Processing Unit Fuse Replacement
Parts replacement Processing Unit fuse replacement The Processing Unit is protected with two ceramic body cartridge fuses on the power inlet. The fuses are replaced if blown. Note These procedures will instruct you to handle electronic circuit boards and/or modules. Before doing so, make sure that you are familiar with the applicable handling precautions.
Page 62: Removing The Fuse In The Processing Unit
Kongsberg EM 712 Maintenance Manual Removing the fuse in the Processing Unit The Processing Unit is protected with two ceramic body cartridge fuses on the power inlet. The fuses are replaced if blown. Follow this procedure to remove the fuses.
Page 63: Installing The Fuse In The Processing Unit
Push the fuse holder in. Connect the power cable on the rear side of the unit. Turn on the Processing Unit. Further requirements Once the unit has been installed, follow the normal procedure to turn on the EM 712. 451106/B...
Page 64: Spare Parts And Consumables
Kongsberg EM 712 Maintenance Manual Spare parts and consumables Topics Ordering spare parts, page 65 List of spare parts - Processing Unit, page 66 List of spare parts - Transmitter Unit, page 69 List of spare parts - Receiver Unit, page 71...
Page 65: Ordering Spare Parts
Spare parts and consumables Ordering spare parts To make the order process as short and efficient as possible, you must provide accurate information about the product, the part you need, and yourself. The following information must be provided with your order: •...
Page 66: List Of Spare Parts - Processing Unit
There are two Compact Beamformer (CBMF) boards in the Processing Unit. This is a generic photo. The CBMF board used by the EM 712 may look slightly different due to minor design changes on the protective lid and/or the front panel.
Page 67: Cpu Board Spare Part 456983
Concurrent Technologies (http://www.gocct.com) Related topics CPU board replacement, page 49 Power supply spare part 373897 One power supply unit is used in the EM 712 Processing Unit for supply of 5, 24 and 48 VDC. • Power supply, Part name: Excesys XLB •...
Page 68: Fan Unit Spare Part 385387
Kongsberg EM 712 Maintenance Manual Fan unit spare part 385387 Two fan units are used in the EM 712 Processing Unit for side to side cooling. • Fan unit Part name: • 385387 Part number: • Number in use: •...
Page 69: List Of Spare Parts - Transmitter Unit
Part number: • Number in use: • Recommended number in spare: • Kongsberg Maritime (https://www.kongsberg.com/maritime/) True manufacturer: TX RIO board spare part 399431 There are up to 10 TX RIO boards in each Transmitter Unit. • TX RIO board Part name: •...
Page 70: Rio-P Board Spare Part 322623
Kongsberg EM 712 Maintenance Manual RIO-P board spare part 322623 There is one RIO-P board in each Transmitter Unit. • RIO-P board Part name: • 322623 Part number: • Number in use: • Recommended number in spare: • Kongsberg Maritime (https://www.kongsberg.com/maritime/)
Page 71: List Of Spare Parts - Receiver Unit
The number of circuit boards in the Receiver Unit will depend on the chosen transducer configuration. • Receiver Unit 1° Part name: • 403302 Part number: • Number in use: • Recommended number in spare: • Kongsberg Mar- True manufacturer: itime (https://www.kongsberg.com/maritime/) 451106/B...
Page 72: Receiver Unit 2° - Spare Part - 403303
Kongsberg EM 712 Maintenance Manual Receiver Unit 2° - spare part - 403303 The complete receiver Unit can be supplied as a spare part. The number of Receiver Units used will depend on the system configuration. The number of circuit boards in the Receiver Unit will depend on the chosen transducer configuration.
Page 73: Receiver Unit 1° - Spare Part - Em 712B 447972
The number of circuit boards in the Receiver Unit will depend on the chosen transducer configuration. EM 712B is an upgrade kit for EM 710 that allows you to upgrade to EM 712 without changing the transducers. • Receiver Unit 1° EM 712B Part name: •...
Page 74: Rxu Power Supply Spare Part 399824
Kongsberg EM 712 Maintenance Manual RXU Power supply spare part 399824 There is one power supply unit in each Receiver Unit. • Power supply Roal RCB600-AB00 Part name: • 399824 Part number: • Number in use: • Recommended number in spare: •...
Page 75: Processing Unit
Processing Unit Processing Unit Topics Processing Unit description, page 76 Processing Unit familiarization, page 76 Processing Unit front panel description, page 77 Processing Unit rear panel description, page 78 Processing Unit circuit boards and modules, page 79 CPU board, page 80 CP219 Ethernet switch, page 83 CBMF board, page 85 451106/B...
Page 76: Processing Unit Description
Kongsberg EM 712 Maintenance Manual Processing Unit description The EM 712 Processing Unit is provided to process the signals to and from the Transmitter and Receiver Units. The EM 712 Processing Unit is an industrial computer using both COTS (commercial off-the-shelf) components and custom made components.
Page 77: Processing Unit Front Panel Description
Processing Unit Processing Unit front panel description The front panel of the Processing Unit holds a mains power switch and an information display. Information display Power On/Off 451106/B...
Page 78: Processing Unit Rear Panel Description
Fuse for the AC mains supply CPU board CBMF board There are one or two Compact Beamformer (CBMF) boards in the Processing Unit. The number of CBMF boards depend upon the configuration of the EM 712 system. CP219 Ethernet switch Air filter unit 451106/B...
Page 79: Processing Unit Circuit Boards And Modules
The Processing Unit has two fan units for cooling purposes. • Power supply One power supply unit is used in the EM 712 Processing Unit for supply of 5, 24 and 48 VDC. The Excelsys XLB power supply is located inside the Processing Unit, and is not visible from the outside.
Page 80: Cpu Board
Concurrent PP833 CPU board connectors, page 82 Concurrent PP B12 CPU board overview Concurrent PP B12 is one version of CPU board used in the EM 712 Processing Unit. The Concurrent PP B12 is a PC-compatible high functionality Compact PCI (cPCI) board used by the EM 712 Processing Unit as the Central Processing Unit (CPU).
Page 81: Concurrent Pp B12 Cpu Board Connectors
Station) Concurrent PP833 CPU board overview Concurrent PP833 is one version of CPU board used in the EM 712 Processing Unit. The Concurrent PP833 is a PC-compatible high functionality Compact PCI (cPCI) board used by the EM 712 Processing Unit as the Central Processing Unit (CPU).
Page 82: Concurrent Pp833 Cpu Board Connectors
Concurrent PP833 CPU board connectors The Concurrent PP833 CPU board holds two large connectors for the backplane, as well as several front mounted connectors. Not all of these connectors are used in the EM 712. PMC/XMC1 Console - for Kongsberg Maritime use only COM1 to COM4 - Four serial ports with RJ45 connectors.
Page 83: Cp219 Ethernet Switch
Ethernet switch connectors, page 84 Ethernet switch overview The VadaTech CP219 board is used as an Ethernet switch in the EM 712 Processing Unit. This is a generic photo. The Vadatech CP219 board used by the EM 712 may look slightly different due to minor design changes on the protective lid and/or the front panel.
Page 84: Ethernet Switch Connectors
Kongsberg EM 712 Maintenance Manual Ethernet switch connectors The VadaTech CP219 Ethernet switch holds 10 front mounted connectors, as well as one large connector for the backplane. This is a generic photo. The Vadatech CP219 board used by the EM...
Page 85: Cbmf Board
The Compact Beamformer (CBMF) board is used by the Processing Unit for beamforming and signal processing purposes. This is a generic photo. The CBMF board used by the EM 712 may look slightly different due to minor design changes on the protective lid and/or the front panel.
Page 86: Cbmf Board Configuration
When a board is provided as a spare part, it is readily configured. This is a generic photo. The CBMF board used by the EM 712 may look slightly different due to minor design changes on the protective lid and/or the front panel.
Page 87: Cbmf Board Connectors
The CBMF board holds a large connector for the backplane, as well as several front mounted connectors. This is a generic photo. The CBMF board used by the EM 712 may look slightly different due to minor design changes on the protective lid and/or the front panel.
Page 88: Transmitter Unit
Kongsberg EM 712 Maintenance Manual Transmitter Unit Topics Transmitter Unit description, page 89 Transmitter Unit bottom panel description, page 89 Transmitter Unit top panel description, page 91 RIO-P board - dip switch setting, page 92 451106/B...
Page 89: Transmitter Unit Description
Transmitter Unit Transmitter Unit description The EM 712 Transmitter Unit has all transmit electronics, like control processors, power amplifiers, power supply, capacitor battery and Ethernet interface. The Transmitter Unit is a wall-mounted steel cabinet with integrated shock and vibration absorbers, designed for bulkhead mounting.
Page 90 There are up to 10 TX RIO boards in each Transmitter Unit. The transducer cables connect to the TX RIO boards. The number of TX RIO boards depends on the configuration of the EM 712 system. • 0.25° TX array: 20 (2x10) •...
Page 91: Transmitter Unit Top Panel Description
There are up to 20 LPTX36 Transmitter boards in each Transmitter Unit. Each LPTX36 board is connected to the Ethernet switch in the Transmitter Unit. The number of LPTX36 boards depends on the configuration of the EM 712 system. • 0.25° TX array: 40 (2x20) •...
Page 92: Rio-P Board - Dip Switch Setting
Kongsberg EM 712 Maintenance Manual RIO-P board - dip switch setting The dip switch setting on the RIO–P board has to be correct. Transmitter Unit 1 (MASTER): All switches must be set to ON. The position of the dip switches are shown with...
Page 93: Receiver Unit
Receiver Unit Receiver Unit Topics Receiver Unit description, page 94 Receiver Unit front panel description, page 95 Receiver Unit - dip switch setting, page 96 451106/B...
Page 94: Receiver Unit Description
Kongsberg EM 712 Maintenance Manual Receiver Unit description The EM 712 Receiver Unit has all receive electronics, like control processor, amplifiers, Analog-to-Digital Converters, power supply and Ethernet interface. The Receiver Unit is a small wall-mounted steel cabinet with integrated shock and vibration absorbers, designed for bulkhead mounting.
Page 95: Receiver Unit Front Panel Description
Receiver Unit Receiver Unit front panel description The connectors and circuit boards of the Receiver Unit are accessed from the front. The transducer cables connect to the receiver Unit. The number of cables will depend on the chosen transducer configuration. 451106/B...
Page 96: Receiver Unit - Dip Switch Setting
Kongsberg EM 712 Maintenance Manual Receiver Unit - dip switch setting The dip switch setting in the Receiver Unit has to be correct. For a 0.5° transducer array, two Receiver Units are used. The software in the Processing Unit must know the identification of the Receiver Units.
Page 97 Receiver Unit One Receiver Unit All switches must be set to OFF. OFF is when they are pushed up. Two Receiver Units Receiver Unit 1: all switches must be set to OFF. OFF is when they are pushed up. Receiver Unit 1 is connected to RX transducer 1. Receiver Unit 2: switch 1, 2 and 3 must be set to OFF, switch 4 must be set to ON.
Page 98: Hydrographic Work Station
Kongsberg EM 712 Maintenance Manual Hydrographic Work Station Topics Hydrographic Work Station description, page 99 Hydrographic Work Station front panel description, page 99 Hydrographic Work Station rear panel description, page 100 451106/B...
Page 99: Hydrographic Work Station Description
Hydrographic Work Station Hydrographic Work Station description The Hydrographic Work Station is the operator station for the EM 712. A dedicated maritime computer is provided with the EM 712 Multibeam echo sounder . It is set up with all necessary software.
Page 100: Hydrographic Work Station Rear Panel Description
Kongsberg EM 712 Maintenance Manual Hydrographic Work Station rear panel description The rear panel of the Hydrographic Work Station holds all the connectors used by the computer to communicate with external devices. It also holds the power input socket and a mains power switch.
Page 101: Drawing File
375817 Combined casing w/mounting frame - 1°, page 118 331369 Casing w/mounting frame - 2°, page 119 396402 EM 712 Transmitter Unit dimensions, page 120 212984 EM 712 Transmitter Unit mounting bracket, page 121 396428 EM 712 Receiver Unit dimensions, page 122 385422 Processing Unit dimensions, page 123...
Page 102: 216148 Transducer Tx1 Dimensions
Kongsberg EM 712 Maintenance Manual 216148 Transducer TX1 dimensions 451106/B...
Page 103 Drawing file 451106/B...
Page 104: 221048 Transducer Tx2 Dimensions
Kongsberg EM 712 Maintenance Manual 221048 Transducer TX2 dimensions 451106/B...
Page 105 Drawing file 451106/B...
Page 106: 219621 Transducer Rx1 Dimensions
Kongsberg EM 712 Maintenance Manual 219621 Transducer RX1 dimensions 451106/B...
Page 107 Drawing file 451106/B...
Page 108: 216146 Transducer Rx2 Dimensions
Kongsberg EM 712 Maintenance Manual 216146 Transducer RX2 dimensions 451106/B...
Page 109 Drawing file 451106/B...
Page 110: 223137 Transducer Mounting Frame - 0.5
Kongsberg EM 712 Maintenance Manual 223137 Transducer mounting frame - 0.5° 451106/B...
Page 111 Drawing file 451106/B...
Page 112: 223139 Transducer Mounting Frame - 1
Kongsberg EM 712 Maintenance Manual 223139 Transducer mounting frame - 1° 451106/B...
Page 113 Drawing file 451106/B...
Page 114: 223273 Transducer Mounting Frame - 2
Kongsberg EM 712 Maintenance Manual 223273 Transducer mounting frame - 2° 451106/B...
Page 115 Drawing file 451106/B...
Page 116: 317812 Casing W/Mounting Frame - 0.5
Kongsberg EM 712 Maintenance Manual 317812 Casing w/mounting frame - 0.5° 451106/B...
Page 117: 320320 Casing W/Mounting Frame - 1
Drawing file 320320 Casing w/mounting frame - 1° 451106/B...
Page 118: 375817 Combined Casing W/Mounting Frame - 1
Kongsberg EM 712 Maintenance Manual 375817 Combined casing w/mounting frame - 1° 451106/B...
Page 119: 331369 Casing W/Mounting Frame - 2
Drawing file 331369 Casing w/mounting frame - 2° 451106/B...
Page 120: 396402 Em 712 Transmitter Unit Dimensions
Kongsberg EM 712 Maintenance Manual 396402 EM 712 Transmitter Unit dimensions 451106/B...
Page 121: 212984 Em 712 Transmitter Unit Mounting Bracket
Drawing file 212984 EM 712 Transmitter Unit mounting bracket 451106/B...
Page 122: 396428 Em 712 Receiver Unit Dimensions
Kongsberg EM 712 Maintenance Manual 396428 EM 712 Receiver Unit dimensions 451106/B...
Page 123: 385422 Processing Unit Dimensions
Drawing file 385422 Processing Unit dimensions 451106/B...
Page 124: 378828 Hydrographic Work Station Dimensions
Kongsberg EM 712 Maintenance Manual 378828 Hydrographic Work Station dimensions 451106/B...
Page 125 Drawing file 451106/B...
Page 126: 371591 Rack Installation Kit Dimenisons
Kongsberg EM 712 Maintenance Manual 371591 Rack installation kit dimenisons 451106/B...
Page 127: 370275 Remote Control Unit (K-Rem) Dimensions
Drawing file 370275 Remote Control Unit (K-REM) dimensions 451106/B...
Page 128 Kongsberg EM 712 Maintenance Manual 451106/B...
Page 129: 373962 Remote Control Unit (K-Rem) Wiring Diagram
Drawing file 373962 Remote Control Unit (K-REM) wiring diagram 451106/B...
Page 130: 409067 Fibre Cable Kit
Kongsberg EM 712 Maintenance Manual 409067 Fibre cable kit 451106/B...
Page 131: Technical Specifications
Technical specifications Technical specifications Topics Performance specifications, page 132 Interface specifications, page 134 Weight and outline dimensions, page 142 Power requirements, page 145 Environmental requirements, page 146 Alignment specifications, page 149 451106/B...
Page 132: Performance Specifications
Kongsberg EM 712 Maintenance Manual Performance specifications These performance specifications summarize the main functional and operational characteristics of the EM 712 system. • Maximum ping rate: More than 30 Hz • Number of swaths per ping: 2 • Number of beams and soundings System version 0.25 x 0.5...
Page 133 2900 2800 Summer * Estimated depth and coverage for EM 712, based on BS= -20dB, NL= 35 dB, f = 40 kHz Dual swath restrictions FM mode is used to extend the maximum range capability. Since the relative ping rate increases at large depths (caused by reduced angular coverage), the need for dual swath decreases with depth.
Page 134: Interface Specifications
Kongsberg EM 712 Maintenance Manual Interface specifications Topics Different datagram formats, page 134 Interface specifications - Processing Unit - all format, page 135 Interface specifications - Processing Unit - KMall format, page 138 External sensor requirements, page 140 Interface specifications - Hydrographic Work Station - all format, page 141...
Page 135: Interface Specifications - Processing Unit - All Format
Contact our customer support line for assistance in upgrading existing systems. Interface specifications - Processing Unit - all format The EM 712 system will interface with peripheral systems and sensors using standard and/or proprietary datagram formats. This is a description of available datagram formats for EM multibeams using all format.
Page 136 The NMEA ZDA datagram contains the universal time code (UTC), day, month, year and local time zone. Supported datagram formats for heading information The EM 712 supports the following datagram formats for vessel heading and/or gyro information. These datagram formats are received using a serial communication line.
Page 137 Technical specifications Supported datagram formats for motion information The EM 712 supports the following datagram format from a motion sensor. These datagram formats are received using a serial communication line. • Kongsberg EM Attitude 3000 The EM Attitude 3000 is a proprietary datagram format created by Kongsberg Maritime for use with digital motion sensors.
Page 138: Interface Specifications - Processing Unit - Kmall Format
Kongsberg EM 712 Maintenance Manual Interface specifications - Processing Unit - KMall format The EM 712 system will interface with peripheral systems and sensors using standard and/or proprietary datagram formats. This is a description of available datagram formats for EM multibeams using KMall format.
Page 139 Sound speed probe can be interfaced directly to the Processing Unit and configured in K-Controller or interfaced to the Hydrograpic Work Station and configured in SIS 5. The EM 712 supports the following datagram format from a sound speed probe. •...
Page 140: External Sensor Requirements
Heave Doppler shifts All new generation of multibeam echo sounders from Kongsberg Maritime have an extended range performance by use of a frequency modulated transmitter pulse (FM), also called chirp pulse. In the FM mode, the Doppler shift made by the movements of the survey vessel relative to the bottom, causes a range error.
Page 141: Interface Specifications - Hydrographic Work Station - All Format
Interface specifications - Hydrographic Work Station - all format The EM 712 system will interface with peripheral systems and sensors using standard and/or proprietary datagram formats. This is a description of available datagram formats for EM multibeams using all format.
Page 142: Weight And Outline Dimensions
Kongsberg EM 712 Maintenance Manual Weight and outline dimensions These weights and outline dimension characteristics summarize the physical properties of the EM 712 system. For more detailed information about the physical dimensions, see the Drawing file. Transmit transducer module – TX1 – 1°...
Page 143 • : 11 kg Weight Hydrographic Work Station : Hewlett Packard MP5810 Make and model The standard commercial computer has been configured to fit the operational requirements of the EM 712. • Outline dimensions – : 379 mm Depth –...
Page 144 Kongsberg EM 712 Maintenance Manual – : 408 mm Height • : 10 kg (Approximately) Weight 451106/B...
Page 145: Power Requirements
Technical specifications Power requirements These power characteristics summarize the supply power requirements for the EM 712 system. Note The use of an Uninterruptible Power Supply (UPS) is highly recommended. TX Unit • : 230 Vac, 47 to 63 Hz Voltage requirement •...
Page 146: Environmental Requirements
Kongsberg EM 712 Maintenance Manual Environmental requirements These specifications summarize the temperature requirements and other environmental standards for the EM 712 system. Transducer • : -5 to +50 °C Operational temperature • : -30 to +70 °C Storage temperature •...
Page 147 Technical specifications Receiver Unit • : 0 to 50 °C Operational temperature • : –30 to 70 °C Storage temperature • : 5 to 93% relative non-condensing Relative humidity • : IP23 Ingress protection • Vibration – : 5 to 100 Hz Frequency range –...
Page 148 Kongsberg EM 712 Maintenance Manual Display • : Isic Manufacturer • http://www.isic-systems.com Manufacturer’s website • : MD22/24/27 (DuraMON WS 22/24/27) Make and model • : -15 to 55 °C Operating temperature • : -25 to 70 °C Storage temperature •...
Page 149: Alignment Specifications
Technical specifications Alignment specifications These alignment specifications summarize the alignment accuracy requirements of the EM 712 system. Note The following accuracy requirements are minimum requirements. Higher accuracy will provide better results and should therefore always be aimed at. Transducer alignment accuracy TX array •...
Page 150 Kongsberg EM 712 Maintenance Manual Position sensor alignment accuracy • : ± 0.05 m Position (x) • : ± 0.05 m Position (y) • : ± 0.02 m Position (z) Waterline determination accuracy • : ± 0.02 m Position (z)
Page 151: Cable Layout And Interconnections
Cable layout and interconnections Topics Read this first, page 152 Cable plans, page 153 List of EM 712 cables, page 164 Transmit transducer cables, page 168 Receive transducer cables, page 173 Clock synchronization (1PPS), page 177 External synchronization, page 179...
Page 152: Read This First
: These cables may be provided by Kongsberg Maritime as a part Commercial cables of the EM 712 delivery. They may also be included with third party items that are used with the EM 712. All electronic installations and corresponding wiring must be in accordance with the vessel's national registry and corresponding maritime authority and/or classification society.
Page 153: Cable Plans
Cable layout and interconnections Cable plans Topics Cable plan - Processing Unit, page 154 Cable plan - Transmitter Unit, page 155 Cable plan - Receiver Unit, page 160 Cable plan, Hydrographic Work Station, page 163 451106/B...
Page 154: Cable Plan - Processing Unit
Kongsberg EM 712 Maintenance Manual Cable plan - Processing Unit The Processing Unit cables include those used to connect the EM 712 Processing Unit to AC mains power, and to the transmitter and receiver units. One Ethernet cable is used to connect the Processing Unit to the Hydrographic Work Station.
Page 155: Cable Plan - Transmitter Unit
Cable layout and interconnections Cable plan - Transmitter Unit The transmitter (TX) Unit cables include those used to connect the EM 712 TX Unit(s) to AC mains power, to the receiver (RX) Unit, to the Processing Unit and to the transducers.
Page 156 Kongsberg EM 712 Maintenance Manual Transmitter Unit 1 Cables identified with an asterisk (*) are system cables. These cables are supplied with the EM 712 delivery. 451106/B...
Page 157 Cable layout and interconnections Transmitter Unit 1 RIO-P board TX RIO board 1 TX RIO board 10 Transmit transducer module number 1 Transmit transducer module number 2 Transmit transducer module number 3 Transmit transducer module number 4 Cables from Transmit Transducer 3 and 4 are connected to Transmitter Unit 2 according to the cable identification table 451106/B...
Page 158 Kongsberg EM 712 Maintenance Manual Transmitter Unit 2 Cables identified with an asterisk (*) are system cables. These cables are supplied with the EM 712 delivery. 451106/B...
Page 159 Transmit transducer module number 2 Transmit transducer module number 3 Transmit transducer module number 4 Cables from Transmit Transducer 1 and 2 are connected to Transmitter Unit 1 according to the cable identification table Related topics List of EM 712 cables, page 164 451106/B...
Page 160: Cable Plan - Receiver Unit
Kongsberg EM 712 Maintenance Manual Cable plan - Receiver Unit The receiver (RX) Unit cables include those used to connect the EM 712 RX Unit(s) to AC mains power, to the transmitter (TX) Unit, to the Processing Unit and to the transducers.
Page 161 Cable layout and interconnections Cables identified with an asterisk (*) are system cables. These cables are supplied with the EM 712 delivery. 451106/B...
Page 162 During the installation of the transducer array, you must fill in the cable identification table. The number of cables depends on the chosen system configuration. • 0.5° receive transducer: 8 cables • 1° receive transducer: 4 cables • 2° receive transducer: 2 cables Related topics List of EM 712 cables, page 164 451106/B...
Page 163: Cable Plan, Hydrographic Work Station
Cable layout and interconnections Cable plan, Hydrographic Work Station The topside/bridge cables include those used to connect the EM 712 Hydrographic Work Station and the display to each other, to AC mains power, and to external devices. Hydrographic Work Station Display The Hydrographic Work Station supports up to three displays.
Page 164: List Of Em 712 Cables
Kongsberg EM 712 Maintenance Manual List of EM 712 cables A set of cables is required to connect the EM 712 units to each other, and to the relevant power source(s). The following cables are used when the EM 712 is set up.
Page 165 Cable layout and interconnections Cable Signal From/To Minimum requirements Control cable From Processing Unit to remote control device Remote on/off switch If remote control is not used, a termination plug has to be inserted in the Remote control plug on the Processing Unit. This plug is a 9 pin D-SUB supplied with the Processing Unit.
Page 166 Kongsberg EM 712 Maintenance Manual Cable Signal From/To Minimum requirements Fibre optic cable From Transmitter Unit 2 to Receiver Unit 1 The fibre optic cable and the cable for remote control between the Transmitter Units and Receiver Units are delivered as a kit.The standard cable length is 10 metres.
Page 167 Identifying EM 712 cables on a project cable drawing The EM 712 is often a part of a project delivery. For such deliveries, specific project cable drawings are established to show all the main cables, and how the various products are connected.
Page 168: Transmit Transducer Cables
Kongsberg EM 712 Maintenance Manual Transmit transducer cables The cables between the EM 712 transmit transducer array and the Transmitter Unit are supplied by Kongsberg Maritime. The number of cables depends on the chosen system configuration. The cables are moulded to the transducers and connect to the Transmitter Unit with connectors.
Page 169 Cable layout and interconnections Default orientation of transducer modules, top view, 0.5° x 0.5° system. Each transducer module is identified by its physical location in the array. If mounting is in accordance with the default orientation, the most aft module is transmit transducer number 1 The location of the transducer modules must be recorded during installation and written down in the...
Page 170 Kongsberg EM 712 Maintenance Manual Optional orientation of transducer modules, top view, 0.5° x 0.5° system. Each transducer module is identified by its physical location in the array. If optional orientation is used, the most forward module is transmit transducer number 1. The location...
Page 171 Cable layout and interconnections Table 1 Cable identification table TX module TX Unit Size of system Posi- Transducer serial number Cable Unit TX RIO Soc- board tion (fill in) 2° 1° 0.5° 0.25° 451106/B...
Page 172 Kongsberg EM 712 Maintenance Manual TX module TX Unit Size of system 451106/B...
Page 173: Receive Transducer Cables
Cable layout and interconnections Receive transducer cables The cables between the EM 712 receive transducer array and the Receiver Unit are supplied by Kongsberg Maritime. The number of cables depends on the chosen system configuration. The cables are moulded to the transducers and connect to the Receiver Unit with connectors.
Page 174 Kongsberg EM 712 Maintenance Manual Default orientation of transducer modules, top view, 0.5° x 0.5° system. Each transducer module is identified by its physical location in the array. If mounting is in accordance with the default orientation, the port side module is receive transducer number 1.
Page 175 Cable layout and interconnections Optional orientation of transducer modules, top view, 0.5° x 0.5° system. Each transducer module is identified by its physical location in the array. If optional orientation is used, the most starboard fide module is receive transducer number 1. The location of the transducer modules must be recorded during installation and written down in the cable...
Page 176 Kongsberg EM 712 Maintenance Manual Connection of receive transducer cables Note During the installation of the transducer array, you must fill in the cable identification table. The number of cables depends on the chosen system configuration. • 0.5° receive transducer: 8 cables •...
Page 177: Clock Synchronization (1Pps)
The Processing Unit has a 1PPS (one pulse per second) input for clock synchronization. This is a generic photo. The CBMF board used by the EM 712 may look slightly different due to minor design changes on the protective lid and/or the front panel.
Page 178 Kongsberg EM 712 Maintenance Manual Two examples are shown to clarify. • Using +4.5 V input signal the input current will be as required (~10 mA). No additional resistance required. • An added resistor of 750 Ω and minimum 0.1 W must be used.
Page 179: External Synchronization
The Processing Unit is has a connection for interface to an external synchronization system. This is a generic photo. The CBMF board used by the EM 712 may look slightly different due to minor design changes on the protective lid and/or the front panel.
Page 180 Kongsberg EM 712 Maintenance Manual External synchronization signal characteristics Signal Description Type Active Ready To Send - Output High from EM 712 when it Open collector output is ready for the next from isolation unit trigger pulse TRIG OUT Trigger out -...
Page 181 Cable layout and interconnections Two examples are shown to clarify. • Using +4.5 V input signal the input current will be as required (~10 mA). No additional resistance required. • An added resistor of 750 Ω and minimum 0.1 W must be used. Optically isolated output signals Processing Unit output circuitry External power...
Page 182: Hydrographic Work Station Rear Connectors
It is very important that high-quality Ethernet cables are used. You must use CAT-5E STP (Shielded Twisted Pair) quality or better. If you use cables with lower bandwidth capacity you will reduce the EM 712 performance. Display Port Display cable: From Hydrographic Work Station to display (C1) This is a commercial cable.
Page 183 Cable layout and interconnections Computer cable: From Hydrographic Work Station to keyboard (C3) The cable is often physically attached to the keyboard, and terminated in the “computer end” with a male PS/2 or USB connector. Depending on the type of connector you must connect the keyboard to the PS/2 connector or an USB connector on the computer.
Page 184: Cable Drawings And Specifications
Kongsberg EM 712 Maintenance Manual Cable drawings and specifications Topics RS-232 serial line using three wires and RJ45 connector, page 185 RS-422 serial line using five wires and RJ45 connector, page 186 Adapter for D-connector to RJ45 connector for RS-422, page 187...
Page 185: Rs-232 Serial Line Using Three Wires And Rj45 Connector
Cable layout and interconnections RS-232 serial line using three wires and RJ45 connector An RS-232 serial line connection using three (3) wires is a common way to connect the EM 712 to external devices. Local connection RJ45 connector Connection on remote device...
Page 186: Rs-422 Serial Line Using Five Wires And Rj45 Connector
RS-422 serial line using five wires and RJ45 connector An RS-422 serial line connection is a common way to connect the EM 712 to external devices. An RS-422 serial line connection can transmit data at rates as high as 10 million bits per second, and may be sent on cables as long as 1500 meters.
Page 187: Adapter For D-Connector To Rj45 Connector For Rs-422
Cable layout and interconnections Adapter for D-connector to RJ45 connector for RS-422 You can use an adapter if you need to connect a serial cable with a D-connector to the Processing Unit. The Processing Unit has four serial ports with RJ45 connectors. The ports can be configured to be RS-232 or RS-422.
Page 188: Clock Synchronisation (1Pps) Using A Coax Cable
Kongsberg EM 712 Maintenance Manual Clock synchronisation (1PPS) using a coax cable The Processing Unit is equipped with a 1PPS signal input for clock synchronisation. Male BNC connector Ground 1PPS signal This cable must be provided by the installation shipyard.
Page 189: External Synchronisation
The connector is RJ45 type. Local connection The connector is RJ45 type. Note Pin 3 and 6 is used by Kongsberg Maritime only. Connection on remote device Unless otherwise specified, this cable must be provided by the installation shipyard.
Page 190: Remote Control Overview
The EM 712 system can be switched on/off with a central control switch. An EM 712 system has several hardware units, and to make it easier to switch on/off the system it is prepared for remote control. There are several methods to do this: •...
Page 191 Cable layout and interconnections Receiver Unit 2, connector marked REMOTE ON/OFF OUT Note The number of Transmitter Units and Receiver Units depends upon the chosen system configuration. The diagram shows the principle for a maximum possible solution, with two Transmitter Units and two Receiver Units.
Page 192: Remote Control
Kongsberg EM 712 Maintenance Manual Remote control The Processing Unit can be switched on/off with a remote switch. This switch is connected to a 9–pin D-connector on the Processing Unit. Local connection, male 9–pin D-connector Connection to remote lamp and on/off switch Female 9–pin D-connector...
Page 193: Remote Control Using K-Rem
Cable layout and interconnections Remote Control using K-Rem The Processing Unit can be switched on/off with a remote switch. This switch is connected to a 9–pin D-connector on the Processing Unit. A dedicated junction box with on/off switches and light indication has been designed for this purpose (K-Rem). Local connection, male 9–pin D-connector Connection at the terminal strip in Remote Control Unit (K-Rem )
Page 194: Dummy Plug For Not Using Remote Control
Kongsberg EM 712 Maintenance Manual Dummy plug for not using remote control The Processing Unit can be switched on/off with a remote switch. If remote control is not used, the enclosed remote control dummy plug has to be inserted in the Remote Control connector in the Processing Unit.
Page 195: Remote Control Of Transmitter Unit
Transmitter Unit from the Processing Unit. Processing Unit end, male 4–pin Lemo connector. Lemo part number: FGG.3B.304.CLAD62Z . Kongsberg Maritime part number: 348015 Transmitter Unit end, male 9–pin D-connector Processing Unit end Pin layout male 4–pin Lemo connector.
Page 196 Kongsberg EM 712 Maintenance Manual Transmitter Unit end Pin layout male 9–pin D-connector. Connects to on the RIO-P board REMOTE ON/OFF IN at the bottom of the Transmitter Unit. Minimum cable requirements • : 2 x 0.5 mm² Conductors •...
Page 197: Remote Control Of Receiver Unit
Cable layout and interconnections Remote control of Receiver Unit Cable for switching on/off the Receiver Unit from the Processing Unit. This cable between the Transmitter Unit and the Receiver Unit is required if you want to switch on and off the Receiver Unit from the Processing Unit. Transmitter Unit end, male 9–pin D-connector Connects to at the bottom of the Transmitter Unit.
Page 198 Kongsberg EM 712 Maintenance Manual Transmitter Unit end Pin layout male 9–pin D-connector. Connects to on the RIO-P board REMOTE ON/OFF OUT at the bottom of the Transmitter Unit. 451106/B...
Page 199 Cable layout and interconnections Receiver Unit end Pin layout male 9–pin D-connector. Connects to at the Receiver Unit. REMOTE ON/OFF IN Minimum cable requirements • : 2 x 0.5 mm² Conductors • : Overall braided Screen • : 60 V Voltage 451106/B...
Page 200 Kongsberg EM 712 Maintenance Manual • : Defined by the plugs Maximum outer diameter This cable must be provided by the installation shipyard. 451106/B...
Page 201: Dimensional Surveying And Alignment
Dimensional surveying and alignment Dimensional surveying and alignment Topics About dimensional surveying and alignment, page 202 Dimensional surveying, page 202 Alignment, page 203 Transducer array flatness, page 203 Checking the transducer array flatness and correcting deviations, page 204 Calibration, page 205 Vessel coordinate system, page 206 451106/B...
Page 202: About Dimensional Surveying And Alignment
Kongsberg EM 712 Maintenance Manual About dimensional surveying and alignment The EM 712 Multibeam echo sounder is a precision instrument for high quality data collection. In order to obtain precision data that are both detailed and correct, it is necessary to align the transducer, measure the location and offset of each sensor in relation to the vessel’s...
Page 203: Alignment
Alignment To ensure a successful installation of the EM 712, all alignment and measurements must be done to the highest possible accuracy. The alignment tasks required for EM 712 include: •...
Page 204: Checking The Transducer Array Flatness And Correcting Deviations
Kongsberg EM 712 Maintenance Manual • No point on the frame may deviate from the ideal plane with more than the tolerance limit shown in Technical specifications. The limit will vary between the different multibeam echo sounders. Ideal plane Installed plane Deviation •...
Page 205: Calibration
Repeat the procedure until the tolerances are met Calibration During the sea trials, calibration surveys are required as described in the EM 712 end user documentation. In order to check and verify the performance of the EM 712 system, we strongly recommend that calibration surveys are done at regular intervals, or prior to any large survey.
Page 206: Vessel Coordinate System
Kongsberg EM 712 Maintenance Manual Note Calibration must be taken seriously. The final verification of correct installation can only be done during calibration at sea. Installation and operational parameters that do not meet the accuracy requirements may lead to incorrect data. To achieve the best results, the calibration must be planned and done carefully.
Page 207 Dimensional surveying and alignment In order to establish a system to measure the relative distance between sensors, a virtual coordinate system is established. This coordinate system uses three vectors; X, Y and Z. The X-axis is the longitudinal direction of the vessel, and in parallel with the deck.
Page 208: Equipment Handling
Kongsberg EM 712 Maintenance Manual Equipment handling Observe these basic rules for transportation, storage and handling of units. In this context, a unit may be any large or small part of the system. It can be supplied as part of the initial delivery, or as a spare part. The phrase box is used to describe all kinds of cases, wooden or cardboard boxes etc used to hold the unit.
Page 209: Transporting Kongsberg Maritime Equipment
In the absence of other information, no other boxes must be stacked on top of it. Handle all boxes and units with care. Note Due to the nature of Kongsberg Maritime’s products, and the extensive use of delicate electronic parts, all units and boxes must be regarded and handled as fragile equipment.
Page 210: Lifting Units And Transportation Boxes
Kongsberg EM 712 Maintenance Manual Lifting units and transportation boxes Some of the boxes used to hold equipment units may be heavy. Use caution when lifting. Prerequisites Units and boxes may be heavy. Make sure that you have the necessary equipment required for lifting heavy items.
Page 211 Equipment handling Note Due to the nature of Kongsberg Maritime’s products, and the extensive use of delicate electronic parts, all units and boxes must be regarded and handled as fragile equipment. 451106/B...
Page 212: Inspection Of Units And Transportation Boxes After Arrival
Describe the damage, and collect photographic evidence if possible. Return the inspection report to Kongsberg Maritime as soon as possible. If units are not damaged, check the humidity absorbing material. If required, dry or replace the bags, then re-pack the unit(s) according to the packing instructions.
Page 213: Specifications For Storage Prior To Installation Or Use
Equipment handling Specifications for storage prior to installation or use When a system, a unit or a spare part has been delivered to the customer, it may be subject to long time storage prior to installation and use. General specifications During this storage period, certain specifications must be met.
Page 214 Kongsberg EM 712 Maintenance Manual Caution Units containing lithium or alkaline batteries must be handled separately and with care. Such units are marked accordingly. Do not attempt to recharge such batteries, open them, or dispose of them by incineration. Refer to the applicable product data sheets or battery handling procedures for further details.
Page 215: Unpacking Instructions
If a unit has been damaged, prepare an inspection report stating the condition of the unit and actions taken. Describe the damage, and collect photographic evidence if possible. Return the inspection report to Kongsberg Maritime as soon as possible. 451106/B...
Page 216: Unpacking Mechanical Units
Kongsberg EM 712 Maintenance Manual Place the box on a stable work bench or on the floor with the top of the box facing upwards. In the absence of other instructions, always open the top of the carton first. The contents of the box will normally have been lowered into the carton from above, so this will usually be the easiest route to follow.
Page 217: Unpacking Electronic And Electromechanical Units
Describe the damage, and collect photographic evidence if possible. Return the inspection report to Kongsberg Maritime as soon as possible. Assuming all is well, open the bag and remove the unit. Take out and keep the documentation.
Page 218: Unpacking Transducers
Kongsberg EM 712 Maintenance Manual Unpacking transducers Prior to installation or use, transducers, sonar heads and hydrophones must be unpacked from their transport boxes. It is important that this unpacking is done without inflicting damage to the equipment. Prerequisites Observe the procedure for unpacking of standard parts and units.
Page 219 Equipment handling Observe the handling rules for transducers. 451106/B...
Page 220: Specifications For Storage After Unpacking
Do not break the seal to open a circuit board package before the board is to be used. If the board package is returned to Kongsberg Maritime with the seal broken, we will assumed that the unit has been used, and then you will be billed accordingly.
Page 221 Equipment handling Note Unless otherwise specified, transducers and hydrophones must not be stored in temperatures below −10°C and above +50°C. 451106/B...
Page 222 Kongsberg EM 712 Maintenance Manual Index 19-inch rack installation kit BIST (Built-In Self Test) outline dimensions........126 introduction ..........23 1PPS BIST (Built-In Self test) dialog box clock synchronisation ......... 188 description ..........19 connection ..........188 block 373897 diagram............ 12 power supply ..........
Page 223 Index links............86 description ..........80 overview ..........85 installing ..........51 purpose ............ 85 removing ..........50 removing ..........56 replacing ..........49 replacement ..........55 CPU Concurrent PP B12 spare part..........66 spare part..........67 switches ........... 86 CPU test CBMF test BIST theory..........
Page 224 ........136 unpacking ..........217 electronic unit unpacking ..........217 EM 710 upgrade to EM 712 ........11 handling EM 712B transducers ..........36 upgradefrom EM 710........11 heading information environmental datagram formats ........136 requirements ..........
Page 225 Processing Unit......46 anti-fouling paints ........41 replace the VadaTech CP219 Ethernet switch ..52 introduction transport Kongsberg Maritime equipment..209 BIST (Built-In Self Test) ....... 23 unpack a hydrophone........218 computer ..........16, 99 unpack a mechanical unit ......216 Processing Unit ........
Page 226 Kongsberg EM 712 Maintenance Manual alignment specifications ......149 computer ..........124 mounting frame Processing Unit ........123 drawing........110, 112, 114 Receiver Unit........... 122 transducer ......102, 104, 106, 108 datagram formats ........ 137–138 Transmitter Unit........120 Transmitter Unit mounting bracket....121 overview CBMF board..........
Page 227 9 replacing the VadaTech CP219 Ethernet rear panel description switch ............ 52 Hydrographic Work Station ....100, 182 transporting Kongsberg Maritime Processing Unit .......... 78 equipment ..........209 receive transducer unpacking a hydrophone ......218 cable identification table ......176 unpacking a mechanical unit ......
Page 228 Kongsberg EM 712 Maintenance Manual CPU board ..........49 RX Unit ..........147 VadaTech CP219 Ethernet switch ..... 52 TX Unit ..........146 requirements signal characteristics ac mains power......... 145 clock synchronization ......... 177 environmental .......... 146 external synchronization ......179, 189 humidity..........
Page 229 ....... 215 104, 106, 108 upgrade storage temperature........146 from EM 710 ..........11 unpacking ..........218 to EM 712..........11 weight ........... 142 transducer handling important rules ........... 36 transmit transducer VadaTech CP218 Ethernet switch cable identification table ......
Page 230 Kongsberg EM 712 Maintenance Manual connectors..........84 description ..........83 installing ..........54 overview ..........83 purpose ............ 83 removing ..........53 replacing ..........52 vessel coordinate system origin ............ 207 principles..........206 vibration RX Unit ..........147 TX Unit ..........146 visual inspection transportation boxes ........

Kongsberg EM 712 Maintenance Manual

Quick Links

Troubleshooting

Related Manuals for Kongsberg EM 712

Summary of Contents for Kongsberg EM 712
