Electrical Connections - M&C EC-30C Instruction Manual

To tighten the connectors onto the PVDF heat exchanger, hold a
Note
wrench against the spanner flats of the bushing!
After assembling all lines check the leak tightness of the PVDF tube connectors.

8.8 Electrical connections

Wrong supply voltage can destroy your cooler!
ATTENTION
When connecting the equipment, make sure that the supply voltage
is identical with the information provided on the model type plate!
There are two EC-30C versions available: 115 V and 230 V. Make sure to operate each ver-
sion with the appropriate supply voltage stated on the model type plate.
The installation and commissioning of the device must conform to
the requirements of VDE 0100 (IEC 364) 'Regulations on the Installa-
Note
tion of Power Circuits with Nominal Voltages below 1000 V' and must
be in compliance with all relevant regulations and standards.
There are five cable fittings at the bottom of the EC-30C, where all electrical connections
can be lead through.
You can open the front of the EC-30C by loosening the four front screws. The front of the
cooler is hooked into the bottom plate with a guide rail and can be tilted to up to 90°
forwards. The power supply electronics are inside the housing on the right. All necessary
connections can be plugged in here without removing the shielding plate.
Fig. 37 shows all available electrical connections.
