Technical Data

Series EC
©
Part No.:
Gas connection
Condensate connections
Material of sample contacting
parts
Single stream, gas flow rate
Gas pressure
Ambient temperature
Storage temperature
Sample outlet dew point
Sample inlet temperature
Water vapor dew point input
Cooling capacity
Main power connection /
Power consumption
Start up time
Dead space
∆P at 250 Nl/h flow rate
Electrical connection
mA-output
Relay output alarm
Relay output warning
Relay output freezer units I and
II
Case protection
Electrical equipment standard
Method of mounting
Case color
Dimension (w x h x d)
Weight
* (a)Addition to the part number for EC-30C with 115 V
** For the given input conditions, please have a look at the table on page 15 chapter '5.1 Max.
possible water vapor dew point input [°C] / [°F]' .
EC-30C | 1.00.02 +49 2102 935 888
Version EC-30C
02 K 6100 (a)*
DN 4/6 tube connector
3x tube connector GL25-12 mm
Duran Glass, PTFE, PVDF
90 Nl/h – 250 Nl/h
max. 3 bar abs.
+5 °C to +45 °C (+41 °F to +113 °F)
-20 °C to +60 °C (~-4 °F to +140 °F)
-20 °C to -30 °C (default -30 °C) (~-4 °F to ~-22 °F, default
~-22 °F)
max. 180 °C (+356 °F)
max. 70 °C (+158 °F)
max. 130 kJ/h** (at given input conditions)
230 V, 50 Hz, 380 VA
or* Part-No. ...-a=115 V, 60 Hz, 380 VA
< 60 min
approx. 160 ml (5.41 fl. oz)
5 mbar
2.5 mm (0.0039 in ) terminals, cable glands PG (1 x 12
2 2
mm, 2 x 16 mm, 2 x 20 mm)
0 - 20 mA / 4 - 20 mA, max. 500 Ohm load (including
cable resistance),
1 changeover contact: 230 V AC 3 A, 24 V DC 3 A
alarm: COM & NC closed
No alarm: COM & NO closed
1 NO contact, 24 V (AC/DC), 0.5 A
warning: open
1 NO contact, 24 V (AC/DC), 0.5 A
unit I on: closed
unit II on: open
IP20, EN 60529
EN 61010
19" rack or wall mount
RAL 9003
84 HP x 8U (with connections) x 360 mm (14.17")
39.34 kg (86.73 lbs)
