Use only the original M&C spare parts!
Only the use of the original tubing set guarantees a perfect
operation!
Note
Never lubricate tubing!
Before mounting the pump, check all parts for contaminations and
clean if necessary.
Put the conveying belt
„
pump body;
Press conveying belt at the recessed grips and simultaneously turn the S-bolt
„
anticlockwise until it snaps;
Switch on the EC-30C.
„

10.1.2 Changing the contact pulley and springs

While mounting, make sure that the center of rotation and the driver
Note
are aligned.
Use genuine spare parts only!
Follow these instructions to change the contact pulley and springs:
Disconnect the cooler from the power supply.
„
Unscrew the nut of the pump head (wrench size 5.5).
„
Remove the pump head from the motor shaft. Now the driver can be removed
„
from the pump head and is ready for maintenance.
The removal of the springs (4 pcs.) away from the driver is possible without any
„
tools. Therefore press together the spring and pull it out of the groove in the
driver, respectively out of the boring of the roll shaft. Now the roll shaft can be
dismounted and the contact pulleys can be replaced.
Assemble the pump in reversed order.
„

10.1.3 Cleaning the pump head

Aggressive condensate possible!
Media residues in tubing!
WARNING
Chemical burns caused by aggressive media possible!
Wear protective clothing and glasses!
We recommend to clean the parts with a dry cloth. Solvent should not be used, because
it can damage the plastics and synthetic rubber parts. Use oil-free compressed air to clean
the parts if available.
