7.9 Parameter menu

The parameter menu is used for setting the individual parameters e.g. service interval or
deep-cooling temperature. The parameter menu has two screens. You can switch be-
tween these screens by using the UP and DOWN buttons.
You can reach the parameter menu from the temperature diagram of the deep-cooling
units by pressing the DOWN button.

Fig. 22: How to reach the parameter menu (screen 1)

The first parameter screen shows the following information:
Operating time of the EC-30C
„
Requested service interval
„
Settings for the mA-output
„
1
2
3

Fig. 23: Parameter menu, screen 1

1
Line 1: operating time
3
Line 3: mA-output
EC-30C | 1.00.02 +49 2102 935 888
PRG ESC
PRG ESC
2
Line 2: Service interval in days
www.mc-techgroup.com
34
