12.3 Spare parts and consumables

The replacement interval for spare parts and consumables depends on the specific oper-
ating condition of the analyzer. The quantities recommended in the following table are
based on experience. Your replacement intervals will be based on your operating
conditions.
The product label with the serial number is located on the back of the EC-30C.
Type and name of the product
(C) Consumables
(R) recommended spare parts
(S) spare parts
Part-No. Name
90 K 6215 0-20 V Module
90 K 6210 Main electronics (Var 1)
90 K 6200 Power supply electronics (Var 1)
90 K 6205 Rectifier electronics (Var 1)
90 K 6220 Main adapter
EE 02710005 Rectifier capacitor
90 K 6265 Converter
90 K 6225 Fuse set* EC-30C 230 V
90 K 6225a Fuse set* EC-30C 115 V
90 K 1002 Temperature sensor pre-cooling unit PCU
90 K 0040x Temperature sensor deep-cooling unit DCU
93 K 0047 Peltier element
90 K 6245 O-ring set** Silicone EC-30C
90 K 1014 Cooling aggregate 230 V
90 K 1014a Cooling aggregate 115 V
90 K 1055 Starting capacitor: compressor 230 V: 80 µF
90 K 1060 Starting capacitor: compressor 115 V: 160 µF
90 K 6001 Heat exchanger glass DCU
02 K 9105 Heat exchanger glass PCU
90 K 6003 Heat exchanger PVDF DCU
02 K 9300 Heat exchanger PVDF PCU
90 K 0115 Heat conductivity paste (50 g)***
90 K 6040 Solenoid valve 230 V
90 K 6041 Solenoid valve 115 V
90 K 0042 Fan 230 V
90 K 0042a Fan 115 V
EZ 0024 Display controller TCU
91 B 8600 Key-pad
EC-30C | 1.00.02 +49 2102 935 888
recommended amount
based on number of
years of operation [years]
C/R/S
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
www.mc-techgroup.com
1 2 3
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- 1 1
- 1 1
1 1 1
1 1 1
1 1 1
1 1 1
- - -
- - -
- - -
- - -
- - -
- - -
