Components
Alarm type
Liquid alarm
Device
temperature
Voltage error
General device
Only for
M&C Service
Personnel
31
EC-30C | 1.00.02
Symbol Code
Description
Liquid
30
alarm 1
Liquid
alarm 2
31
(only for M&C
service
personnel)
Device
32
temperature
too high
Device
33
temperature
too low
Couplings
capacitor or
34
bridge rectifier
defect
I
C communi-
2
35
cation doesn't
work
I
C communi-
2
36
cation doesn't
work
One internal
voltage supply
37
(5 V or 12 V) is
incorrect
H/K Relay unit
38
1 defect
H/K Relay unit
39
2 defect
+49 2102 935 888
Comments
T
≥ +80 °C (176 °F)
Gerät
T
≤ +2 °C (35.6 °F)
Gerät
One IC doesn't
answer; probably IC
defect
All IC's don't answer
(probably power
cord defect or
removed)
5 V voltage < 4.5 V
12 V Voltage < 9 V
Cools down, but
does not heat up, or
heats up, but does
not cool down
Cools down, but
does not heat up, or
heats up, but does
not cool down
www.mc-techgroup.com
