Installation instructions and mounting of the EC-30C

Heavy device!
Risk of injury when handling heavy equipment.
CAUTION
Do not lift, move or carry the device without help. A second person is
required to lift, move or carry the device.
The cooler EC-30C is suitable for both: wall and 19" rack mounting.

8.1 Installation instructions

Follow these installation instructions:
The operating position of the cooler is exclusively upright. The operation in
vertical position ensures the faultless separation and removal of the conden-
sate in the heat exchanger.
Mount the cooler in a ventilated place away from heat sources. This way you
avoid disturbing heat accumulations.
When mounted outdoors, the cooler has to be installed into a protective case.
Make sure that the place of operation is frost-free in winter and sufficiently
ventilated in summer. Avoid direct sunlight.
Take into consideration the required minimum assembly dimensions.
For optimum measurement results we recommend to use an electrically
heated gas sample line.
Heated sample gas lines need to end at least 20 cm (7.874") before the gas line
reaches the cooler to make sure that the heated sample line and the cooler is
thermally decoupled. That means, the last 20 cm (7.874") of the gas lines are not
isolated.
Un-heated sample gas lines need to be installed with a declining angle towards
the cooler. In this case, any built-up condensate in the gas lines can flow
towards the cooler and will be removed by the heat exchanger in the pre-cool-
er unit.
EC-30C | 1.00.02
