Options
Part-No.: 01 P 9145
Part-No.: 03 F 3000
Part-No.:
02 K 9700 (a)*
Part-No.: 03 E 1001
Part-No.: 03 E 3500
Part-No.: 02 K 9710
* (a)Addition to the part number for EC-30C with 115 V
5.1 Max. possible water vapor dew point input [°C] / [°F]
This table shows the max. possible water vapor dew point input (°C) / (°F) depending on
the incoming gas temperature and the flow rate.
These values correspond to the maximum cooling capacity of 130 kJ/h. The maximum
possible water vapor dew point input (°C) / (°F) indicated must not be exceeded.
Incoming gas temperature in °C (°F)
Gas flow [l/h]
70
(158 °F)
90
70
(158 °F)
110
68
(154.4 °F)
130
65
(149 °F)
150
62
(143.6 °F)
170
59
(138.2 °F)
190
57
(134.6 °F)
210
55
(131 °F)
230
53
(127.4 °F)
250
52
(125.6 °F)
15
EC-30C | 1.00.02
Peristaltic pump SR25.2, to mount into the EC-30C (See
spare parts for SR25.2 on page 70 chapter '12.3
Spare parts and consumables' )
Aerosol-Filter CLF-5: External mounting in the outlet of
an ultra low gas cooler EC-30C when sample tends to
form aerosols.
Technical data see data sheet 7.7 Fluid particle filter
CLF-5
Heat-exchanger purging: 4. peristaltic pump with
solenoid valve
LA 1S humidity sensor, 4 m (13.12 ft) cable with cable
breakage detection
FA 20 (Flow sensor with 0.45 m [1.48 ft] cable)
FM 40 (Flow meter, 25-250 Nl/h)
90
120
(194 °F)
(248 °F)
70
69
(158 °F)
(156.2 °F)
67
66
(152.6 °F)
(150.8 °F)
64
63
(147.2 °F)
(145.4 °F)
61
59
(141.8 °F)
(138.2 °F)
58
56
(136.4 °F)
(132.8 °F)
56
54
(132.8 °F)
(129.2 °F)
54
52
(129.2 °F)
(125.6 °F)
52
49
(125.6 °F)
(120.2 °F)
50
47
(122 °F)
(116.6 °F)
+49 2102 935 888
150
180
(302 °F)
(356 °F)
68
67
(154.4 °F)
(152.6 °F)
65
63
(149 °F)
(145.4 °F)
61
59
(141.8 °F)
(138.2 °F)
58
56
(136.4 °F)
(132.8 °F)
55
53
(131 °F)
(127.4 °F)
52
50
(125.6 °F)
(122 °F)
49
46
(120.2 °F)
(114.8 °F)
47
43
(116.6 °F)
(109.4 °F)
44
41
(111.2 °F)
(105.8 °F)
