The screens of the parameter menu are independent screen pages.
You can change only the parameters of the screen that is currently
Note
displayed. If you want to change parameters from a different parame-
ter screen, you have to leave the current setting level first by pressing
the ESC button.
The first parameter of the parameter menu will be highlighted. You can switch between
the parameters of this screen page with the PRG button.
First you have to invert the parameter you want to change. Then you use the UP and
DOWN button to switch between the different parameter ranges.
You can exit this screen without changing any parameter by pressing the ESC button.
To accept the value shown on the display, please press the PRG button for about 3 sec-
onds. The parameter will change from highlighted to not highlighted. This means that the
value has been set to the new parameter. You can also change more than one parameter
on the screen, and accept all of them by pressing the PRG button for 3 seconds.
You can exit this program level by pressing the ESC button.
Please find more details about the program levels on page 67
Note
chapter '12.1 Overview of the EC-30C screens' .

7.10 Device information

Please start from the parameter menu (screen 2) and press the DOWN button to change
to the device information screen.

Fig. 26: How to reach the device information

37
EC-30C | 1.00.02
PRG ESC
