Chapter 2: Jumpers and Connectors

Fan Connectors

Connector type: 1x4 4-pin Wafer
Connector location: CN1, CN2, CN3, CN4 and CN5
1 4
Pin Definition
1 GND
2 P12V
3 TACH
4 PWM
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.

VGA Connector

Connector type: 2x8 16-pin header
Connector location: VGACONN1
2 16
1 15
Pin Definition
1 DACROA_B
3 DACBOA_B
5 GND
7 GND
9 VGA_VCC
11 N/A
13 AHSYNCO_B
15 DDC_CLKO_B
10
Pin Definition
2 DACGOA_B
4 N/A
6 GND
8 GND
10 GND
12 DDC_DATAO_B
14 AVSYNCO_B
16 N/A
