Chapter 4: BIOS Setup
SATA And RST Configuration
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Advanced Chipset
SATA And RST Configuration
SATA Controller(s) [Enabled]
SATA Mode Selection [AHCI]
► Software Feature Mask Configuration
Serial ATA Port 0(CF) Empty
Software Preserve Unknown
Port 0 [Enabled]
[Disabled]
Spin Up Device
SATA Device Type [Hard Disk Drive]
Topology [ISATA]
SATA Port 0 DevSlp [Disabled]
DIT0 Configuration [Disabled]
DIT0 Value 625
DM Value 15
Empty
Serial ATA Port 1
Software Preserve Unknown
Port 1 [Enabled]
Hot Plug [Disabled]
Configured as eSATA Hot Plug supported
Spin Up Device [Disabled]
SATA Device Type [Hard Disk Drive]
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
SATA Controller(s)
Enables or disables the SATA controller.
SATA Mode Selection
Configures the SATA mode. The options are AHCI and Intel RST Premium.
Port 0, Port 1, Port 2, Port 6 and Port 7
Enables or disables SATA port 0, port 1, port 2, port 3, port 6 and port 4.
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
▲
Enable/Disable SATA Device.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
▼
43
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Advanced Chipset
Topology [ISATA]
[Disabled]
SATA Port 1 DevSlp
DIT0 Configuration [Disabled]
DIT0 Value 625
DM Value 15
Serial ATA Port 2 Empty
Software Preserve Unknown
Port 1 [Enabled]
Hot Plug [Disabled]
Configured as eSATA Hot Plug supported
Spin Up Device [Disabled]
SATA Device Type [Hard Disk Drive]
Topology [ISATA]
SATA Port 2 DevSlp [Disabled]
DIT0 Configuration [Disabled]
DIT0 Value 625
DM Value 15
Serial ATA Port 3 Empty
Software Preserve Unknown
Port 2 [Enabled]
Hot Plug [Disabled]
Configured as eSATA Hot Plug supported
Spin Up Device [Disabled]
SATA Device Type [Hard Disk Drive]
Topology [ISATA]
[Disabled]
SATA Port 3 DevSlp
DIT0 Configuration [Disabled]
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
Hot Plug
Enables or disables hot plugging feature on SATA port 1, port 2, port 3, port
6 and port 4.
Spin Up Device
Enables or disables staggered spin up on devices connected to SATA port 0,
port 1, port 2, port 3, port 6 and port 4
SATA Device Type
Identifies what type of SATA device is connected.
▲
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
▼
