Chipset - Nexcom NSA 5170C User Manual

Chapter 4: BIOS Setup

Chipset

This section gives you functions to configure the system based on the
specific features of the chipset. The chipset manages bus speeds and access
to system memory resources.
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Main Advanced Chipset Security
System Agent (SA) Configuration
►
PCH-IO Configuration
►
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
PCH-IO Configuration
This field is used to configure PCH parameters.
System Agent (SA) Configuration
This field is used to configure System Agent (SA) parameters.
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
Boot Save & Exit
System Agent (SA) Parameters
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
System Agent (SA) Configuration
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Main Advanced Chipset
System Agent (SA) Configuration
SA PCIe Code Version
VT-d
► Memory Configuration
► Graphics Configuration
PEG Port Configuration
►
VT-d
X2APIC Opt Out
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
Memory Configuration
Configures the memory settings.
Graphics Configuration
Configures the graphics chip settings.
PEG Port Configuration
Configures the PEG Port settings.
VT-d
Enables or disables VT-d function on MCH.
X2APIC Opt Out
Enables or disables X2APIC mode.
40
Save & Exit
Boot Security
Memory Configuration
Parameters
2.3.0.0
Supported
[Enabled]
[Disabled]
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
