Chapter 4: BIOS Setup
SATA And RST Configuration Cont.
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Advanced
Chipset
DIT0 Value
625
15
DM Value
Serial ATA Port 6(CN6)
Empty
Software Preserve
Unknown
Port 6
[Enabled]
Hot Plug
[Disabled]
Configured as eSATA
Hot Plug supported
Spin Up Device
[Disabled]
SATA Device Type
[Hard Disk Drive]
Topology
[Unknown]
SATA Port 6 DevSlp
[Disabled]
DIT0 Configuration
[Disabled]
DIT0 Value
625
DM Value
15
Serial ATA Port 4
Empty
Software Preserve
Unknown
Port 7
[Enabled]
Hot Plug
[Disabled]
Configured as eSATA
Hot Plug supported
Spin Up Device
[Disabled]
SATA Device Type
[Hard Disk Drive]
Topology
[Unknown]
SATA Port 7 DevSlp
[Disabled]
DIT0 Configuration
[Disabled]
DIT0 Value
625
DM Value
15
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
Topology
Identifies what type of SATA connection is used.
SATA Port 0, Port 1, Port 2, Port 3, Port 6 and Port 4 DevSlp
Enables or disables SATA Port 0, Port 1, Port 2, Port 3, Port 6 and Port 4
DevSlp. Before enabling DevSlp, board rework is needed.
DIT0 Configuration
Enables or disables DIT0 configuration for SATA Port 0, Port 1, Port 2, Port
3, Port 6 and Port 4.
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
▲
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
▼
44
Network Configuration
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Chipset
Slot1 Model Name:
Device is Not Found
Slot2 Model Name:
Device is Not Found
Slot3 Model Name:
Device is Not Found
Slot4 Model Name:
Device is Not Found
Slot5 Model Name:
Device is Not Found
Slot6 Model Name:
Device is Not Found
Slot7 Model Name:
Device is Not Found
Slot8 Model Name:
Device is Not Found
ByPass Auto Detect
[Enabled]
Power_ON ByPass Mode
[Disabled]
Power_OFF ByPass Mode
[Disabled]
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
ByPass Auto Detect
Enables or disables automatic LAN Bypass function.
Power_ON ByPass Mode
Enables or disables the LAN module bypass mode after the system powers on.
Power_OFF ByPass Mode
Enables or disables the LAN module bypass mode after the system powers off.
Switch ByPass Auto Detect to
Enable/Disable
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
NSA 5170C User Manual
