Chapter 4: BIOS Setup
Trusted Computing
This section is used to configure Trusted Platform Module (TPM) settings.
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Advanced
TPM20 Device Found
Vendor: IFX
Firmware Version: 5.62
Security Device Support [Enable]
SHA-1,SHA256
Active PCR banks
Available PCR banks SHA-1,SHA256
SHA-1 PCR Bank [Enabled]
SHA256 PCR Bank [Enabled]
Pending operation [None]
[Enabled]
Platform Hierarchy
Storage Hierarchy [Enabled]
Endorsement [Enabled]
Hierarchy
TPM2.0 UEFI Spec [TCG_2]
Version
Physical Presence [1.3]
Spec Version
TPM 20 [TIS]
InterfaceType
Device Select [Auto]
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
Security Device Support
Enables or disables BIOS support for security device. O.S will not show
Security Device. TCG EFI protocol and INT1A interface will not be available.
SHA-1 PCR Bank
Enables or disables SHA-1 PCR Bank.
SHA256 PCR Bank
Enables or disables SHA256 PCR Bank.
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
Pending operation
Schedules an operation for the security device.
Platform Hierarchy
Enables or disables platform hierarchy.
Enables or Disables BIOS
support for security device. O.S. Storage Hierarchy
will not show Security Device.
Enables or disables storage hierarchy.
TCG EFI protocol and INT1A
interface will not be available.
Endorsement Hierarchy
Enables or disables endorsement hierarchy.
TPM2.0 UEFI Spec Version
Configures the TPM2.0 UEFI spec version.
→←: Select Screen
↑↓: Select Item
Enter: Select
Physical Presence Spec Version
+/-: Change Opt.
F1: General Help
Configures the physical presence spec version.
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Device Select
TPM 1.2 will restrict support to TPM 1.2 devices. TPM 2.0 will restrict support
to TPM 2.0 devices. Auto will support both TPM 1.2 and 2.0 devices with
the default set to TPM 2.0 devices if not found, and TPM 1.2 devices will be
enumerated.
