Chapter 4: BIOS Setup
PEG Port Configuration
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Chipset
PEG Port Configuration
PEG 0:1:0 Not Present
Enable Root Port [Enabled]
Max Link Speed [Auto]
PEG 0:1:1 Not Present
Enable Root Port [Enabled]
Max Link Speed [Auto]
PCIe Spread Spectrum Clocking [Disabled]
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
Enable Root Port (PEG 0:1:0 and 0:1:1)
Enables or disables the root port.
Max Link Speed
(PEG 0:1:0 and 0:1:1)
Configures the maximum link speed of the PEG device.
PCIe Spread Spectrum Clocking
Enables or disables PCIe Spread Spectrum Clocking for compliance testing.
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
PCH-IO Configuration
Enable or Disable the Root Port
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
SATA and RST Configuration
Enters the SATA and RST configuration sub-menu.
Network Configuration
Enters the network configuration sub-menu.
State After G3
Configures the PCH state after G3.
42
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Chipset
PCH-IO Configuration
► SATA and RST Configuration
► NETWORK CONFIGURATION
State After G3 [Last State]
Power Supply Type ATX
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
SATA Device Options Settings
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
