Chapter 4: BIOS Setup
Serial Port Console Redirection
This section is used to configure the serial port that will be used for console
redirection.
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Advanced
COM0
[Disabled]
Console Redirection
► Console Redirection Settings
COM3
Console Redirection [Enabled]
► Console Redirection Settings
Legacy Console Redirection
► Legacy Console Redirection Settings
Serial Port for Out-of-Band Management /
Windows Emergency Management Services (EMS)
Console Redirection [Enabled]
► Console Redirection Settings
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
Console Redirection
Enables or disables the console redirection.
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
Console Redirection Settings (COM3)
Specifies how the host computer and the remote computer (which the
user is using) will exchange data. Both computers should have the same or
compatible settings.
Console Redirection Enable or
Disable.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Terminal Type
ANSI
VT100
VT100+ Extends VT100 to support color, function keys, etc.
VT-UTF8 Uses UTF8 encoding to map Unicode characters onto 1 or more
Bits Per Second
Selects the serial port transmission speed. The speed must match the other
side. Long or noisy lines may require a lower speed.
34
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Advanced
COM3
Console Redirection Settings
Terminal Type [VT100+]
Bits per second [115200]
Data Bits [8]
Parity [None]
Stop Bits [1]
Flow Control [None]
VT-UTF8 Combo Key Support [Enabled]
Recorder Mode [Disabled]
Resolution 100x31 [Disabled]
Putty KeyPad [VT100]
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
Extended ASCII character set.
ASCII character set.
bytes.
Emulation: ANSI: Extended
ASCII char set. VT100: ASCII
char set. VT100+: Extends
VT100 to support color, function
keys, etc.
VT-UTF8: Uses UTF8 encoding
to map Unicode chars onto 1
or more
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
