Chapter 2: Jumpers and Connectors

GPIO Pin Header

Connector type: 2x5 10-pin header
Connector location: JP1
2 10
1 9
Pin Definition
1 P3V3
3 SW_GPIN1
5 SW_GPIN2
7 SW_GPIN3
9 SW_GPIN4
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 GND
4 SW_GPOUT1
6 SW_GPOUT2
8 SW_GPOUT3
10 SW_GPOUT4

TPM Header

Connector type: 2x7 14-pin header, 2.0mm pitch
Connector location: JP3
2 14
1 13
Pin Definition
1 GND
3 N/A
5 LPC_AD2_R1
7 LPC_AD1_R1
9 GND
11 INT_SERIRQ_R1
13 GND
13
Pin Definition
2 CLK_LPC_TPM_R
4 LPC_FRAME_R1_N
6 RST_TPM_R1_N
8 LPC_AD3_R1
10 LPC_AD0_R1
12 P3V3
14 GND
