Chapter 2: Jumpers and Connectors
System Fan Connectors (4-Pin)
Connector type: 1x4 4-pin Wafer, 2.54mm pitch
Connector location: FAN1 and FAN3
1
4
Pin
Definition
1
GND
2
VCC12
3
Sense
4
FANPWM
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
System Fan Connectors (3-Pin)
Connector type: 1x3 3-pin Wafer, 2.54mm pitch
Connector location: FAN2 and FAN4
1
3
Pin
Definition
1
GND
2
VCC12
3
Sense
18
NSA 3150 User Manual
