Chapter 4: BIOS Setup
Serial Port 4 Configuration
This section is used to configure serial port 4.
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Advanced
Serial Port 4 Configuration
Serial Port [Enabled]
Device Settings IO=3F8h; IRQ=4;
Change Settings [Auto]
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
Serial Port
Enables or disables the serial port.
Change Settings
Selects an optimal setting for the Super IO device.
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
Hardware Monitor
This section is used to monitor hardware status such as temperature, fan
speed and voltages.
Enable or Disable Serial Port
(COM)
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
CPU and System Temperature
Detects and displays the current CPU and system temperature.
CPU FAN Speed
Detects and displays the current CPU fan speed.
Fan2 to Fan5 Speed
Detects and displays the current fan2 to fan5 speed.
CPU:Vcore to 1.2V
Detects and displays the output voltages.
33
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Advanced
Pc Health Status
: +60 C
CPU Temperature
System Temperature : +36 C
CPU FAN Speed(CN3) : 4192 RPM
Fan2 Speed(CN1) : N/A
Fan3 Speed(CN2) : 4192 RPM
Fan4 Speed(CN4) : N/A
Fan5 Speed(CN5) : N/A
CPU:Vcore : +1.020 V
3.3V : +3.346 V
12V : +0.72 V
5V : N/A
1.2V : +1.200 V
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
