2.4 Config Menu Function (Config)

Select "Menu > Config" to enter the System Menu interface. The menu is
described as follows:
Config
Conf1
Channel(1/2)
System Comm
USB Type B Connect
GPIB GPIB Address
IP Mode
IP Address
LAN
Subnet Mask
Gateway
System Information
Model
Serial Num
Cpu Version
Mcu Version
Mac Address
Socket Port
Inner Temperature
System Config
Date(YY/MM/DD)
Time(hh/mm/ss)
Brightness
Beep
System Reset
System SelfTest
System Protection Clear
System Log
Please Insert USB Device!
Configuration menu setting
Source Config
Output Speed:
Voltage Range:
Current Sense:
Copyright © Itech Electronic Co., Ltd.
Select the configuration channel.
Communication configuration
Select the USB communication
interface.
The address is adjustable between 1
and 30.
IP mode: MANU/DHCP.
IP address setting.
Set the subnet mask.
Set the gateway.
Instrument
information
Instrument model
Instrument SN
The version of Cpu
The version of Mcu
Network hardware address
Port number
Instrument temperature
System Configuration
System date: Year/Month/Day
System time: Hour/Minute/Second
Set the screen brightness.
Set the keyboard sound
System Reset
System SelfTest
Clear protection status and output
latch status
System Log
information
Please insert the USB periphery
device. After insertion, all operations
will be recorded in the USB.
Source Configuration
Configure the output speed: Fast or
Normal
Configure voltage output range: High
or Low
Configure current sense: High or
Auto
