Conf2
Conf3
Configuring the Output Speed
This option is used for configuring the output speed. The maximum output
speed under Normal mode is 5ms. If a higher speed is required, switch to the
Fast mode, under which, 500us is available at maximum.
Configuring Voltage Range
This option is used for configuring the voltage output range: High and Low.
OVP(V):
Voltage Limit(V):
Current Limit(A):
Output Delay(s)
Source Config
Output-off States:
OCP State:
Trace State:
Trigger Mode:
Ext_ON/OFF State:
Ext_ON/OFF Mode:
Digital Function
Calibration Zero
Current Low Range
Note
Conf1 and Conf3 are for configuration of related menus of single channel, i.e., Channel 1
and Channel 2 should be configured separately. Conf2 is for configuration of related
menus of 2 channels, i.e., the configuration displayed in the Conf2 interface will work for
both Channel 1 and Channel 2 at the same time.
Voltage
range
-15.1V to +15.1V
High
-9.05V to +9.05V
Low
Copyright © Itech Electronic Co., Ltd.
Configure over-voltage protection
Configure voltage output limit
Configure current output limit
Configure output delay
Source configuration information
Configure the Output-off state: High
Impedance, Normal, Zero, Relay off
Configure over-current protection:
ON or OFF
Configure channel output On/Off
synchronizing function: ON or OFF
Configure trigger mode: Internal
(Manual trigger),
Bus (Command trigger) or External
(External signal trigger)
Configure external On/Off control
state: ON or OFF
Configure external On/Off control
mode: Latch or Live
Digital function selection: RIDFi
(power fault indication mode) or
DIGio (common digital I/O interface)
Calibration zero
Set small current zero calibration: On
(turn the zero calibration function
on), Off (turn the zero calibration
function off), Cal (when the zero
calibration function is turned on,
operate the small current zero
calibration)
Voltage output range
CH1
Current output range: -3.05A to +3.05A
Current output range: -5.05A to +5.05A
Basic Operation
CH2
0 to +15.1V
0 to +9.05V
