ITech IT6412 User Manual page 49

5.
6.
Battery characteristic simulation operation
1.
2.
3.
4.
5.
6.
7.
Press the [Select] soft key to recall data group.
Press the [Esc] soft key to return to the Battery Simulation Function
interface.
Press the [Menu] key to enter the Menu Configuration page.
Select "Battery" to enter the Battery Simulation Function interface.
Press the right [Channel 1/2] soft key to select configuring channel CH2.
Press the [Mode] soft key to select test mode.
Use the key or the Knob to select the "Simulator" (blue font
background).Press the [OK] key for confirmation.
Press the [Save] soft key. When the display screen prompts "Please Import
BatteryCH1.csv File", import the external battery characteristic data.

External import: Insert the USB (containing BATTERYCH1.csv
document) to the USB interface on the front panel of power supply.
The IT6412 automatically detects and imports the BATTERYCH1.csv
document.

Internal recall: Select the data group in which recall is required based
on the above steps in "Edit the battery characteristic data" and "Recall
the battery characteristic data group".
Press the [Config] soft key and then input the maximum test current of the
