Table 22 Power LED on the S3100V2-TP-SI/S3100V2-TP-EI switches
LED
Power
10/100Base-TX Ethernet port LEDs
The 10/100Base-TX Ethernet port LEDs show the presence of link, data transmission status, and rate of
a 10/100Base-TX Ethernet ports.
Table 23 10/100Base-TX port LEDs on the S3100V2-TP-SI/S3100V2-TP-EI switches
LED
Link/Act
Speed
Combo interface LEDs
The combo interface LEDs show the presence of link, data transmission status, and port rate of a combo
interface.
Table 24 Combo interface LEDs on the S3100V2-TP-SI/S3100V2-TP-EI switches
LED
Link/Act
Speed

LEDs on the S3100V2-TP-PWR-EI switches

Power LED
The power LED shows the power supplying status on the switch.
Status
Steady green
Off
Status
Steady green
Flashing green
Off
Steady green
Off
Active port
100/1000Base-X SFP port or
10/100/1000Base-T Ethernet port
1000 Mbps SFP
transceiver module
100/1000Bas
e-X SFP port
100 Mbps SFP
transceiver module
10/100/1000Base-T Ethernet port
Description
The switch is powered on.
The switch is powered off or has a power supply problem.
Description
A link is present on the port.
The port is transmitting or receiving data.
No link is present on the port.
The port is operating at 100 Mbps.
The port is operating at 10 Mbps, or no
link is present on the port.
Status
Steady green
Flashing green
Off
Steady green
Off
Steady green
Off
56
Description
A link is present on the port.
The port is transmitting or receiving
data.
No link is present on the port.
The port is operating at 1000 Mbps.
The port is operating at 100 Mbps, or
no link is present on the port.
The port is operating at 1000 Mbps.
The port is operating at 10/100
Mbps, or no link is present on the
port.
