H3C S3100V2 Series Installation Manual page 25

Figure 25 Mount the switch to the rack by using front mounting brackets
1
(1) Front rack posts
Rack mounting by front mounting brackets and a support tray
Follow these steps to mount the switch to the rack by front mounting brackets and a support tray:
Wear an ESD-preventive wrist strap and make sure it makes good skin contact and is well grounded,
Step1
check that the rack is sturdy and well grounded.
Plan the position of the switch in the rack, and fix the supplied support tray to the planned position.
Step2
Install the cage nuts to the corresponding positions on the rack posts.
Step3
Unpack the screws (packed with the front mounting brackets), and install the mounting brackets to the
Step4
switch with the screws, as shown in
Put the switch horizontally on the support tray, and slide the switch into the rack. Use the M6 screws to
Step5
install the front mounting brackets to the front rack posts, as shown in
Rack mounting by using front and rear mounting brackets
Follow these steps to mount the switch to the rack by using front and rear mounting brackets:
Wear an ESD-preventive wrist strap and make sure it makes good skin contact and is well grounded.
Step1
Check that the rack is sturdy and well grounded.
Step2
Unpack the screws (packed with the front mounting brackets), and install the front mounting brackets to
Step3
the switch with the screws, as shown in
3
(2) Switch front panel
Figure 24.
Figure 24.
19
1
2
Figure
(3) Front mounting bracket
25.
