1B530D
1B4350XX0D
1B46XXXX44##50&&0D
54 53 0D
54 45 31 0D
54 45 32 0D
54 45 33 0D
54 45 34 0D
54 45 35 0D
54 45 36 0D
54 45 37 0D
54 45 38 0D
54 45 39 0D
54 45 40 0D
4.8.3 The Operation in RS-232 Mode
Before you start the laser, check the wiring, cooling connection and the most important, the
delivery cable and optic output terminal are OK. Make sure that the interlock is shorted, and the
laser emission button is up (emission disabled). Then start the chiller.
Turn the key to „REM‟ position to start the laser, and system start self-check. If the interlock is
not shorted or the „LASER‟ button is pressed down, the system self- check cannot pass. In this
condition, you must power off the laser, and deal with the problem, then start the laser again.
Wuhan Raycus Fiber Laser Technologies Co., Ltd.
Emission Off
Set the operation to CW mode, XX is
the percentage of output power,
ranging from 0 to 100, and it‟s
hexadecimal.
Set the operation in pulse mode.
XXXX-repetition
50~50000;
##-duty cycle, 0~100;
&&-percentage of output power,
0~100
All parameters are in hexadecimal
Response after code is received
Report Error 1
Report Error 2
Report Error 3
Report Error 4
Report Error 5
Report Error 6
Report Error 7
Report Error 8
Report Error 9
Report Error 10
34
User Guide 1000W/1200W/1500W
Response: 54 53 0D
Sent:1B4350320D
Response: 54 53 0D
Set the operation to CW
mode, percentage of output
power is 50%
Sent:1B461388443C50500D
Response: 54 53 0D
frequency,
Set the operation in pulse
mode,
Repetition frequency-5kHz
Duty cycle-60%
Percentage
power-80%
Ver: 1.0
Sent: 1B530D
of output
\
\
\
\
\
\
\
\
\
\
\
