self-check in hyper terminal mode. Refer to 4.7.3 Operation in Hyper Te rminal Mode for
details.

4.6 Entering a Control Mode

The following diagram shows the process of entering a certain control mode.
Switch on the
laser
Turn the switch to the
'REM' position
AD mode
Figure 11: The Process of Entering Different Control Modes
You can see that, if you want to enter hyper terminal mode, you must turn the key to the „ON‟
position; if you want to enter a remote control mode, you must turn the key to the „REM‟
position. Whether you enter AD mode or RS-232 mode depends on 24V is applied to PIN7 and
PIN9 of the „CTRL-INTERFACE‟ or not.

4.7 Hyper Terminal Mode

Hyper terminal mode is a local control mode. Hyper terminal is a communication tool in
Windows system, so make sure your PC operation system is Windows. In hyper terminal mode,
operation parameters can be set, and errors can be displayed and cleared.
Connect power
supply and interfaces
24V is applied between
AD/RS and EGND of the
'CONRTOL' cable
Turn the switch to the
'ON' position
Hyper
terminal
mode
Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide 1000W/1200W/1500W
AD/RS of the
'CONRTOL' cable
is left disconnected
Switch on the
Turn the switch to the
'REM' position
RS-232
mode
24
Ver: 1.0
laser
Turn the switch to the
'ON' position
Hyper
terminal
mode
