- Page 1 Continuous-Wave Fiber Laser User Guide RFL-C1500X/RFL-C2000X Wuhan Raycus Fiber Laser Technologies Co., Ltd.
-
Page 2: Table Of Contents
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C1500X/C2000X TABLE OF CONTENTS 1 Safety Information....................2 1.1 Symbols Used in this User Guide..............2 1.2 Laser Classification..................2 1.3 Safety Labels....................3 1.4 Optical Safety....................4 1.5 Electrical Safety..................... 4 1.6 Other Safety Rules..................5 2 Product Description....................6... - Page 3 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C1500X/C2000X 4.8 Steps of shutting down.................32 5 Alarms and Solutions..................33 5.1 Alarms Display.................... 33 5.2 Alarm solutions....................33 6 Warranty, Return and Maintenance..............37 6.1 General Warranty..................37 6.2 Limitations of Warranty................37...
-
Page 4: Safety Information
User Guide of RFL-C1500X/C2000X 1 Safety Information Thank you for choosing Raycus fiber laser. This User Guide provides important safety, operation, warranty and other information. Please read it carefully before you use this product. In order to ensure safe operation and optimal performance of the product, please follow the warnings, cautions, operating procedures and other instructions accordingly. -
Page 5: Safety Labels
1.3 Safety Labels The position of the safety labels on products varies depending on the model of the continuous-wave fiber laser, as shown in Figure 1: Figure 1: Safety Label Locations of RFL-C1500X/RFL-C2000X... -
Page 6: Optical Safety
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C1500X/C2000X These safety labels include warning labels, apertures through which laser radiation is emitted and labels of certification and identification, etc. Specifications of these labels are as follows: Table 1: Specifications of Safety Labels (Take 500W for example) 3.Class 2M Laser Product... -
Page 7: Other Safety Rules
(4) There are no operator serviceable parts inside, and all maintenance must be performed in Raycus or by qualified Raycus personnel. Do not try to remove covers, or electrical shock may be caused, and warranty will be void. -
Page 8: Product Description
Cutting, Welding 3D Printing Scientific research 2.2 Model Configuration The series of Raycus continuous-wave fiber laser include 1500W and 2000W, and the model designation codes are illustrated in the following table: Table 2 Model Names and Designation Codes... -
Page 9: Package Contents
Check all items against the list and contact Raycus immediately if there is any missing item or evident damage to the unit. DO NOT attempt to install or operate the laser, if there is any evident or suspected damage to the unit. -
Page 10: Operation Environment
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C1500X/C2000X CAUTION: The fiber optic cable and output head is precise optic instrument, any vibration or impact to the output head, and twist or excessive bend to the cable will damage the instrument. -
Page 11: Precautions For Use
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C1500X/C2000X Temperature （℃） 20% -3.5 14.5 16.5 10.5 16.5 10.5 18.5 21.5 19.5 28.5 27.5 33.5 Laser operating temperature range 2.6 Precautions for Use (1) Before supplying the power to the device, make sure that the correct voltage of the AC power source is used (See Table 3 for the laser model and corresponding input voltage). - Page 12 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C1500X/C2000X Table 5 Specifications Table 6 Product C1500X C2000X Test Conditions SpecificationsModel Optical Specifications Nominal Output Power (W) 1500 2000 Operation Modes CW/Modulated Polarization State Random Output Power Tunability(%) 10~100 Emission Wavelength(nm) 1080±5...
- Page 13 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C1500X/C2000X Other Characteristics 91 3 × 48 0 ×235 ( include. handles ) Dimensions(W×H×D) Weight(kg) <70 Operating Ambient Temperature 10~40 (℃) Humidity (%) <70 Storage Temperature (℃) -10~60 Cooling Method...
-
Page 14: Installation
User Guide of RFL-C1500X/C2000X 3 Installation 3.1 Dimensions Figure 3 shows dimensions of RFL-C1500X/C2000X (take RFL-C2000X for example, RFL-C1500X has the same dimensions). Figure 2 (a) Front panel view of RFL-C1500X/C2000X (unit: mm) Figure 2 (b) Rear panel view of RFL-C1500X/C2000X (unit: mm) -
Page 15: Output Cables And Installation
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C1500X/C2000X Figure 2 (c) Top and Side view of RFL-C1500X/C2000X (unit: mm) 3.2 Output Cables and Installation Figure 3 Dimensions of QBH Output Head... -
Page 16: Cooling Requirements
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C1500X/C2000X The laser output cable of RFL-C1500X/C2000X is Raycus-made. The specific appearance dimensions are shown in Figure 6 above CAUTION: For QBH output cable, there are two interlock pins on the output head, which must be shorted before the laser is turned on. - Page 17 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C1500X/C2000X 3) Requirements for output cable cooling system: Rate of liquid flow: 1.7-2.0 L/min; Pressure of liquid flow: < 0.6 MPa at the inflow; Type of liquid exchange junction: SMC MS-5H-6: ...
-
Page 18: Installation Procedure
(4) Insert the water pipes into the inlet and outlet; (5) Check the output head and clean it if necessary. This procedure must be performed by Raycus personnel or person authorized by Raycus. Make sure the environment is clean, or the output cable may be contaminated. - Page 19 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C1500X/C2000X CAUTION: All the cables can only be connected when power supply is OFF. Hot plug may damage the laser. CAUTION: The laser output optical cable should be kept as natural as possible and not be distorted.
-
Page 20: Using The Product
User Guide of RFL- RFL-C1500X/C2000X 4 Using the Product Raycus CW fiber laser has stopped using the HyperTerminal, so the HyperTerminal will not work when the laser is powered on. Please clip the address below to download the latest PC software and the relevant manual. -
Page 21: Rear Panel
Figure 12 shows the rear panel of RFL-C1500S/C2000S (take RFL-C2000S for example, RFL-C1500S has the same rear panel): Figure 5 Rear Panel View of RFL-C1500X/C2000X 1. AC INPUT: The socket for supply source input that can only be mated with the plug on the power cord we provided. -
Page 22: Power Connection
0.1MPa, the flow rate is 10 LPM, and the outer diameter of pipe mated with the connector is 6mm. If the CDA filter module provided by Raycus is used, the CDA should be also cooled and dried by the dryer, and the pressure should be below 0.8MPa, the outer diameter of pipe mated with the connector is 6mm. -
Page 23: Interface Definitions
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C1500X/C2000X Table 8 Power Connection Requirements Model RFL-C1500X RFL-C2000X 380±10% V AC Supply Source 50/60Hz Power Cord One End of Four wires labeled L1，L2，L3 and PE. Power Cord L1，L2，L3 Phase Line ->... - Page 24 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C1500X/C2000X Response Time NULL Contact 互锁通道 1A Dry contacts pair, connect or Closure 5Vdc <1A <500ms disconnect only 互锁通道 1B Input NULL Transmit Data RS232 Tx RS232 Rx 120ms...
- Page 25 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C1500X/C2000X unconnected, laser enters RS232 mode System error Digital High=System error 24Vdc 100 mA 120ms output （ERROR） NULL NULL Caution: Please check the control voltage level and ensure that the level is in accordance with the requirements.
- Page 26 Step 2: The default password is "1122334455667788". After the verification is passed, read or set the new laser IP address. Step 3: If you use Raycus software to control the laser, you need to find the folder where the Raycus software is located, open the laser configuration file “config.xml”, and write the newly laser IP address.
-
Page 27: Steps Of Installation
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C1500X/C2000X Figure 19 Steps of Ethernet Connection 4.5 Steps of Installation Carefully take out the laser from the box and move it to the installing position and then lock the casters;... -
Page 28: Steps Of Staring
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C1500X/C2000X Install the output cable on the processing equipment according to the actual situation (install the output head cooling water pipe at the same time), pay attention to the output cable and head, then remove the protective cap and confirm that the output lens is clean and install the output head.；... -
Page 29: Control Modes
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C1500X/C2000X 4.7 Control Modes 4.7.1 Wiring in different modes Figure 8 Wiring in RS-232 mode Figure 9 Wiring in AD mode... - Page 30 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C1500X/C2000X 4.7.2 Internal control mode 5) Clockwise the key switch to the “ON” position and the “Power” indicator on the front panel illuminates; 6) Waiting for 10s until the internal main control board circuit initialization is completed;...
- Page 31 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C1500X/C2000X PIN 18, 20 of the DB25 control interface is applied to 24V (enable hardware emission); Send the start or stop emitting command (enable hardware emission) to control the emission by Raycus software;...
- Page 32 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C1500X/C2000X Figure 11 Control sequence diagram of Pulse mode Figure 12 Control sequence diagram of External AD mode...
- Page 33 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C1500X/C2000X Figure 13 Control sequence diagram of Modulation mode Figure 14 Control sequence diagram of Gate mode 4.7.6 Guide Laser control Turn the key switch to the "REM" or "ON" position and power on the laser，“POWER”...
-
Page 34: Steps Of Shutting Down
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C1500X/C2000X 4.8 Steps of shutting down Please turn off the laser in the order below: 1) Turn off the emission; 2) Turn the key switch to the "OFF" position and release “LASER” button;... -
Page 35: Alarms And Solutions
When the laser establishes communication with the client software, all alarm states of the laser can be displayed on Raycus software homepage, as shown in Figure 32(Download the Rsycus software and software manual, please log in to Raycus official website) - Page 36 If there is no red guide light, please stop using the laser immediately and contact Raycus. If the red guide light output normally, please restart the laser to try, if the alarm continues to occur, please contact Raycus.
- Page 37 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C1500X/C2000X ACDC1 Error, failure of the laser power supply or sudden power failure of the power supply system may cause an alarm. Solution: Check if the input AC voltage is normal. Restart the laser, if this error continues to occur, please contact Raycus.
- Page 38 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C1500X/C2000X In addition to the above, if there are any questions or errors in using of the laser, you can contact Raycus to get help.
-
Page 39: Warranty, Return And Maintenance
The warranties start on the date of shipment from Raycus for a period of time as set forth in the applicable purchase contracts or product specifications. Raycus has the right to choose to repair or replace any product that proves to be defective in materials and workmanship selectively during the warranty period. - Page 40 All the items about warranty and service above provided by Raycus are for user’s reference; formal contents about warranty and service are subject to the contract.
