Summary of Contents for Raycus RFL-C3000S
- Page 1 Continuous-Wave Fiber Laser User Guide RFL-C3000S Wuhan Raycus Fiber Laser Technologies Co., Ltd.
-
Page 2: Table Of Contents
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3000S TABLE OF CONTENTS 1 Safety Information........................3 1.1 Symbols Used in this User Guide..................3 1.2 Laser Classification......................3 1.3 Safety Labels........................4 1.4 Optical Safety........................5 1.5 Electrical Safety.........................6 1.6 Other Safety Rules......................6 2 Product Description........................7... -
Page 3: Safety Information
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C3000S 1 Safety Information Thank you for choosingRaycus fiber laser. This User Guide provides important safety, operation, warranty and other information. Please read it carefully before you use this product. In order to ensure safe operation and optimal performance of the product, please follow the warnings, cautions, operating procedures and other instructions accordingly. -
Page 4: Safety Labels
WARNING: You must use appropriate laser safety eyewear when this device is operating. Thelaser safety eyewear is selected according to the range of wavelengths emitted from this product. The end user must ensure that the laser safety eyewear being used protects against light emitted by the device over its entire range of wavelengths. -
Page 5: Optical Safety
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C3000S These safety labels include warning labels, apertures through which laser radiation is emitted and labels of certification and identification, etc. Specifications of these labels are as follows: Table 1: Specifications of Safety Labels (Take 500W for example) 3.Class 2M Laser Product... -
Page 6: Electrical Safety
(4) There are no operator serviceable parts inside, and all maintenance must be performed in Raycus or by qualified Raycuspersonnel. Do not try to remove covers, or electrical shock may be caused, and warranty will be void. -
Page 7: Product Description
Cutting, Welding 3D Printing Scientific research 2.2 Model Configuration The series of Raycus continuous-wave fiber laser include1500W and 2000W, and the model designation codes are illustrated in the following table: Table 2 Model Names and Designation Codes... -
Page 8: Package Contents
Please refer to the packing list accompanying the shipment to check actual items included. 2.4 Unpacking and Inspection Raycus CW fiber laser is shipped in a package designed to provide maximumprotection. Upon delivery, please inspect all packaging for evidence of mishandling or damage. If you find any evidence of mishandling, please save the damaged material and contact the shipping agent and Raycusimmediately. -
Page 9: Operation Environment
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C3000S It is recommended to keep the packing materials, as they will be necessary if you ever need to ship the unit back for service at a later date. -
Page 10: Precautions For Use
TheConstant Dew Point Table Table 4 AMBIENT DEW POINT Maximum Relative humidity Room Temperature （℃） -3.5 14.5 16.5 10.5 16.5 10.5 18.5 21.5 19.5 28.5 27.5 33.5 Laser operating temperature range 2.6 Precautions for Use (1) Before supplying the power to the device, make sure that the correct voltage of the AC power source is used (See Table 3 for the laser model and corresponding input voltage). -
Page 11: Specifications
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C3000S 2.7 Specifications The specifications are listed in the following table Table 5 Specifications Table 6 Product SpecificationsModel C3000S Test Conditions Optical Specifications Nominal Output Power (W) 3000 Operation Modes... -
Page 12: Installation
3 Installation 3.1 Dimensions Figure 22 shows dimensions of RFL-C3000S. Figure 2 (a) Front panel view of RFL-C3000S(unit: mm) Figure2 (b) Rear panel view of RFL-C3000S (unit: mm) -
Page 13: Output Head And Installation
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C3000S Figure2 (c) Top and Side view of RFL-C3000S (unit: mm) 3.2 Output Head and Installation Figure 3aDimensions of QBH Output Head... -
Page 14: Cooling Requirements
Figure 4bDimensions of iQB Output Head The QBH and iQB laser output head of RFL-C3000S are all thestandard QBH interface.The specific appearance and dimensions are shown in Figure 3 above. CAUTIONS: Inspect the output lens before installing the output head to the processing head. - Page 15 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C3000S If the product is used in an environment that ambient temperature is between -10℃ and 0℃, we recommend to use 30% alcohol, and replace it every two months.
-
Page 16: Installation Procedure
(4) Insert the water pipes into the inlet and outlet; (5) Check the output head and clean it if necessary. This procedure must be performed by personnel of Raycus or authorized by Raycus. Make sure the environment is clean, or the output cable may be contaminated. - Page 17 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C3000S (7) During the installation and disassembly process, please take care to handle the laser output head gently, avoiding any shock; (8) In the installation of laser output cable and output head process, please make sure that the surrounding environment is clean, otherwise it may pollute the output head (do not use fans, which actually may bring more dust);...
-
Page 18: Using The Product
PC software and the relevant manual. 4.1 Front Panel Figure 4 shows the front panel of RFL-C3000S(take RFL-C2000 for example)： Figure 5 Front Panel of RFL-C3000S 1. REM/OFF/ON: Key switch, the power switch of the laser. Insert the key; either turning the key clockwise to the 'ON' position or counterclockwise to 'REM' position will power on the laser. -
Page 19: Rear Panel
4.2 Rear Panel Figure 6 shows the rear panel of RFL-C3000S: Figure 6 Rear Panel of RFL-C3000S 1. AC INPUT: The socket for supply source input that can only be mated with the plug on the power cord we provided. -
Page 20: Power Connection
6mm. If the CDA filter module provided by Raycus is used, the CDA should be also cooled and dried by the dryer, and the pressure should be below 0.8MPa, the outer diameter of pipe mated with the connector is 6mm. -
Page 21: Interface Definitions
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C3000S Power Cord One End of Four wires labeledL1，L2，L3and PE. Power Cord L1，L2，L3-> Phase Line Sign PE-> Protective Earth Description One end of the power cord is a plug, insert it into the socket 'AC INPUT' on the rear panel. - Page 22 RS-232 Return RS232Com Activates the internal main Contact Remote Key Closure 24VDC <1A <1s power supply in Switch REMOTE mode Input NULL Analog Input Analog Analog Input 1-10 VDC= to Control 0-10V 1-10VDC 1 mA 300us 10 – 100% Setpoint Input Current Analog Output 0-5 VDC...
- Page 23 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C3000S SERIVCE 4.4.2 Security interface The Service Security Interface is pin 2 and pin 3 of CTRL-INTERFACE. The SERVICE connector is a female DB9 interface. If PIN 6-7 are disconnected, the laser will immediately stop working, and the laser Ready signal will go low.
- Page 24 Step 2: The default password is "1122334455667788". After the verification is passed, read or set the new laser IP address; Step 3: If you use Raycus software to control the laser, you need to find the folder where the Raycus software is located, open the laser configuration file “config.xml”, and write the newly laser IP address.
-
Page 25: Steps Of Installation
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C3000S Figure 8 Steps of Ethernet Connection 4.5 Steps of Installation 1) Carefully takeout the laser from the box and move it to the installing position and then lock the casters;... -
Page 26: Control Modes
3) Turn on the air switch and release the emergency stop switch. Note: RFL-C3000S has an air conditioner and it starts to run as the emergency stop switch is released. In order to avoid damage the laser caused by condensation when the working... - Page 27 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C3000S Figure 10Wiring in AD mode 4.7.2 Internal control mode 5) Clockwise the key switch to the “ON” position and the “Power” indicator on the front panel illuminates; 6) Waiting for 10s until the internal main control board circuit initialization is completed;...
- Page 28 4.7.3 External control mode Modulation Mode:When the duty cycle of the internal pulse is set to 100%, the laser operates in external modulation mode.The laser is controlledby the user's "modulation" signal provided by the external MOD interface. For the time sequencediagram, see [4.7.5 Control sequence diagram].
- Page 29 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C3000S 4.7.4 AD mode When PIN 20, 21 of the DB25 control interface is applied to 24V, the laser enters the external AD mode, and the power of the laser is controlled by the voltage obtained by PIN12, 13(1V-10% power, 10V-100% power).
- Page 30 Figure 12 Control sequence diagram of Pulse mode Figure 13 Control sequence diagram of External AD mode...
- Page 31 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C3000S Figure 14 Control sequence diagram of Modulation mode Figure 15Control sequence diagram of Gate mode 4.7.6 Guide Lasercontrol Turn the key switch to the "REM" or "ON" position and power on the laser，“POWER”...
-
Page 32: Steps Of Shutting Down
4.8 Steps of shutting down Please turn off the laser in the order below: 1) Turn off the emission; 2) Turn the key switch to the "OFF" position and release “LASER” button; 3) Turn off the chiller; 4) If the product have air conditioner please waiting10 minutes for the air conditioner to continue working. -
Page 33: Alarms And Solutions
5.1 Alarms Display When the laser establishes communication with the client software,all alarm states of the laser can be displayed on Raycus software homepage,as shown in Figure 1615(Download the Rsycus software and software manual, please log in to Raycus official website) - Page 34 If there is no red guide light, please stop using the laser immediately and contact Raycus. If the red guide light output normally, please restart the laser to try, if the alarm continues to occur, please contact Raycus.
- Page 35 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL- RFL-C3000S Restart the laser, if this error continues to occur, please contact Raycus. Instruction: ACDC1 Error, failure ofthe laser power supply or sudden power failure of the power supply system may cause an alarm.
- Page 36 Raycus. In addition to the above, if there are any questions or errors inusing of the laser, you can contactRaycus to get help.
-
Page 37: Warranty, Return And Maintenance
The warranties start on the date of shipment from Raycus for a period of time as set forth in the applicable purchase contracts or product specifications. Raycus has the right to choose to repair or replace any product that proves to be defective in materials and workmanship selectively during the warranty period. - Page 38 All the items about warranty and service above provided by Raycus are for user’s reference; formal contents about warranty and service are subject to the contract.
