(6) The optic fiber cable must not be bent with the radius less than 30 cm during transportatio n，
storage and when in use.
There are four swinging rings on the top of the product and four wheels on the bottom, with
which you can lift or move the product. The rings and wheels are shown in Figure 3
Figure 3: The Swinging Rings and Wheels on the Product
1. Swinging rings; 2. Wheels
CAUTION: All the cables can only be connected when power supply is
off. Hot plug may damage the laser.
CAUTION: Ensure that there are no fiber bends with radius less than 30
cm. Avoid excessive twisting and tight bends during the robotic arm
movements. Tight bends will damage the Laser system.
