- Page 1 编号 RFL-C3300X~RFL-C15000 内 1 密级 阶段标记 页数 RFL-C3300X/RFL-C4000X/RFL-C6000X/ 名称 RFL-C8000X/RFL-C10000X/RFL-C12000X/ RFL-C15000 连续光纤激光器英文说明书 会签 武汉锐科-第二事业部 单位 编写 校对 审核 标审 批准 武汉锐科光纤激光技术股份有限公司...
- Page 2 High Power Continuous Wave Fiber Laser Instructions Applicable RFL-C3300X RFL-C4000X RFL-C6000X models： RFL-C8000X RFL-C10000X RFL-C12000X RFL-C15000 Wuhan Raycus Fiber Laser Technologies Co., Ltd.
-
Page 3: Table Of Contents
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W CONTENTS 1 Safety Information........................1 1.1 Security Label........................1 1.2 Laser Safety Grade......................2 1.3 Optical Safety........................2 1.4 Electrical Safety.........................2 1.5 Other Safety Rules......................3 2 Product Description........................4 2.1 Features..........................4 2.2 Package Parts........................4 2.3 Unpacking and Inspection.................... - Page 4 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W 4.12 Real-time power feedback..................... 37 4.13 Light out fault locking....................37 5 Alarms and Possible Solutions....................37 5.1 Read Alarm Logs......................37 5.2 Alarm Solutions....................... 38 6 Warranty, Repair and Return....................40 6.1 General Warranty......................40...
-
Page 5: Safety Information
User Guide of RFL-C3300W~RFL-C15000W 1 Safety Information Thank you for choosing Raycus Fiber Laser. This user manual provides you with important safety, operation, maintenance and other relevant information. Please read the manual carefully before using this product. To ensure safe operation and optimum product operation, please observe the following cautions and warnings as well as other information within this manual. -
Page 6: Laser Safety Grade
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W 1.2 Laser Safety Grade According to European Standard EN 60825-1, Clause 9, this series of lasers are Class 4 laser instruments. The product emits laser radiation at a wavelength of 1080 nm or around 1080 nm, and the average laser power radiated from the output head is 3.3 kW to 15 kW (depending on the machine model), either directly or... -
Page 7: Other Safety Rules
4) There are no user serviceable parts, equipment or assemblies inside the product. All service and maintenance shall be conducted by Raycus engineer. In order to prevent electric shock, please do not break the seal or uncover the shield. -
Page 8: Product Description
Once you find that there is an abnormality in the external cabinet, please inform Raycus Company in time to deal with it as soon as possible. -
Page 9: Operation Environment
User Guide of RFL-C3300W~RFL-C15000W Please double check if each listed contents is inside the package; and contact Raycus as soon as possible if there is any issues. Take extra care when removing the unit from the package to make the fiber optic cable stay away from collision and vibration. -
Page 10: Attentions
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W (5) Do not look into the output head directly. Wear appropriate protective eye glasses all the time when operating the laser. Tips: Install the laser in an air-conditioned environment for longer life and better performance. - Page 11 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W Nominal Output Power; Output ±1.5% Duration: Power 5hrs; Unstability Ambient Temp.: 25℃ Modulation Nominal Frequency( 50～5k 50～2k Output Power Red Guide Laser 0.5～1 Power(mW) Fiber output HQBH Types Nominal...
-
Page 12: Installation
The mechanical appearance dimensions of RFLC3300X/ C4000X/ C6000X/ C8000X/ C10000X/ C12000X/ C15000 continuous wave fiber laser are as follow: (1) The external dimensions of the RFL-C3300X/ C4000X continuous wave fiber laser are shown in Figure 1 (taking RFL-C3300X as an example). - Page 13 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W Figure 1-b Top and left view of the laser. Figure 1 The dimensions of RFL-C3300X continuous fiber laser. The RFL-C3300X/ C4000X two lasers share a set of cabinets. Model RFL-C3300X RFL-4000X...
- Page 14 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W Figure 2-a Front and rear view of the laser. Figure 2-b Top and left view of the laser. Figure 2 The dimensions of RFL-C6000X continuous wave fiber laser. RFL-C6000X / C8000X two lasers share a set of cabinets.
- Page 15 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W Figure 3-a Front and rear view of the laser Figure 3-b Top and left view of the laser. Figure 3 The dimensions of RFL-C12000X continuous wave fiber laser. The RFL-C10000X / C12000X two lasers share a set of cabinets.
- Page 16 800kg Dimensions 960*1600*1180mm(L×W×H) The type and dimensions of RFL-C3300X / C4000X / C6000X / C8000X / C10000X / C12000X / C15000 continuous fiber laser output cable and output cable head are as follows: (1) RFL-C3300X / RFL-C4000X / RFL-C6000X lasers use RFL-HQBH output optical cable, and the dimension of output optical cable head are shown in Figure 5;...
-
Page 17: Installation Rule
If the output cable lens is dirty, the lens must be cleaned. It is forbidden to disassemble the output lens by anyone other than staff in Raycus, otherwise the warranty will be invalidated. - Page 18 User Guide of RFL-C3300W~RFL-C15000W (5) Check the output head and clean it before installation. This procedure must be performed by Raycus personnel or person authorized by Raycus. (6) Prevent the delivery cable from treading, pinching or excessive bending during installation.
-
Page 19: Cooling Requirements
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W CAUTION: All the cables can only be connected when power supply is off. Hot plug may damage the device. CAUTION: (1) Ensure that there are no fiber bends in radius less than 30cm when the product is installed. - Page 20 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W (4) If ambient temperature is below -10 ℃ , the chiller with both heating and cooling functions must be used, and keep it in full-time operation. Requirements for output cable cooling system: (1) Rate of liquid flow: 1.7～2.0 L/min;...
-
Page 21: Using The Product
The Raycus continuous wave fiber laser has stopped using the HyperTerminal. After the laser is powered on, the HyperTerminal has no display. Please log in to the official website of Raycus to download the new PC software and the PC software user manual. -
Page 22: Rear Panel
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W REM/OFF/ON: Key switch, the power switch of the laser. Insert the key and then turn the key clockwise to the 'ON' position or counterclockwise to 'REM' position to active the laser. The laser then enters the corresponding control mode based on the level of the "AD/RS"... - Page 23 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W Interface Dehumidifier Breaker Water input AC input Filter Water output Figure 9-a Rear view of C3.3kW/C4kW product panel.
- Page 24 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W Dehumidifier Interface Breaker Water input Filter AC input Water output Picture 9-b Rear view of C6kW/C8kW product panel. Dehumidifier Interface Breaker Water input Filter AC input Water output Picture 9-c Rear view of C10kW/C12kW product panel.
- Page 25 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W Dehumidifier Interface Water input Breaker Filter AC input Water output Picture 9-d Rear view of C15kW product panel. Figure 9 The picture of laser rear panel. AC INPUT: The socket for supply input that can be only mated with the plug on the power cord we provided.The socket is provided with a protective cover and a...
-
Page 26: Power Connection
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W The circuit breaker which is located on the side panel is the power switch of the device, as shown in Figure 9. 4.3 Power Connection CAUTION: (1) Before connect the product to AC power, you must check up that the AC supply you will apply is in accordance with the specifications provided in Table 1. - Page 27 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W Socket Plug Lock a) The picture of 3.3kW / 4kW power port plug / socket. Socket Plug Lock b) The picture of 6kW / 8kW/ 10kW/ 12kW power port plug / socket.
-
Page 28: Interface Definitions
/10mm Earth -green The standard length of 3.3kW / 4kW provided by Raycus is 8 meters, and the standard length of 6kW / 8kW / 10kW / 12kW / 15kW is 15m. 4.4 Interface Definitions All control signals are shown on the “INTERFACE” port located on the the... - Page 29 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W Figure 12 Control cord. Please insert the control cord we supplied into the “INTERFACE” port on rear panel when using the product, and lock it, as Figure 13 shows.
- Page 30 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W simultaneously. If you use ‘LASER’, left this disconnected; if you use this pin to control emission, keep ‘LASER’ button 0->Emission Disabled; 1->Emission Ready) Control mode selection; the key switch is in the "REM"...
-
Page 31: Operation Mode And Control
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W MOD+ Brown Input port of 24Vmodulation signal MOD- White MODULATION Protective Earth.Connecting the protective earth with the overall shield. Remote protection. “ITL_A” ITL_A Brown and “ITL_B” must be shorted INTERLOCK when the laser is powered on. -
Page 32: Serial Port Communication Mode
RAYCUS, users can type in instruction through PC. Then operations such as setting parameters, reading laser state, and laser emission control can be executed. RAYCUS provides a software that we developed for users to check the laser state and debug simply. The installation environment of the laser client control software should be within the WINDOWS system and Microsoft. -
Page 33: Cable Connection Of Serial Port Communication Mode
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W 4.7.1 Cable Connection of Serial Port Communication Mode LAS_C FEEDBACK 0V~8V Power feedback analog Figure 15 Wiring of Serial Port Communication Mode 4.7.2 Operations in Serial Port Communication Mode... - Page 34 LED will illumine. Double click the RAYCUS laser client control software, then the following interface can be seen in Figure 16. Figure 16 Inteface 1 of the RAYCUS laser client control software. After self-checking of 20 seconds, users can select the corresponding COM in the drop-down box and click “Open serial port”.
- Page 35 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W Figure 17 Inteface 2 of the RAYCUS laser client control software. Verify that the settings are correct (if the signal is sent from front and rear panel, the corresponding status signal will be ticked) and there is no alarm information.
-
Page 36: Rs-232 Mode
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W If users want to continuously emit laser, set the duty ratio to 100% and set the required power percentage. By clicking the “set” button, a message about the successful setting should pop up. Then clicking the light switch and pressing the Laser button on the front panel, or giving the 6-pin Interfaceon the rear panel a 24V signal Laser, can both generate continuous laser with previously set power. -
Page 37: Communication Protocol
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W Please connect the RS-232 cable, control cable and the power cord according to the Figure 19. Make sure that the interlocking signal “ITL_A” and “ITL_B” in “INTERFACE” port is shorted. Confirm that the laser emission button is released and “LAS_C”... -
Page 38: Ad Mode
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W In the RS-232 mode, the conditions of laser emission are: 1) shutter is open, 2) operational parameters are set, 3) input modulation signal is on the high level. 4.9 AD mode AD mode is also an external control mode. -
Page 39: Red Light Control
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W 1) The power wiring and control wiring are connected correctly and the voltage meets product requirements. 2) The “LASER” button on the front panel is up and the 6th pin “LAS_C”... -
Page 40: Water Flow Monitoring
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-C3300W~RFL-C15000W The red indicator indicates emission.Press the laser "LASER" button down or open the shutter through the software by serial port control to close the red light. In RS-232 mode, Press the laser "LASER" button on or close the shutter through the software by serial port control to open the red light. -
Page 41: Real-Time Power Feedback
At the same time the ALARM indicator (Yellow) on the front panel lights on and one string of alarm log is sent at the serial port. Use Raycus Client Software to read the alarm log(s). Opent the client software click ‘Read History Alarm Record’ tab click ‘Read History Erro... -
Page 42: Alarm Solutions
Error water temperature drops to below 30°C, restart the laser to see if the problem is solved. If the alarm continues to happen, please contact Raycus. Low temperature alarm: Check if the water temperature is too low or not.Besides, a low ambient temperature may also cause a low temperature alarm when the laser is cold started. - Page 43 This alarm happens when the power emission cannot reach Laser Power the pre-set value. Solutions: Error Restart the device to see if the problem is solved. If this alarm continues to happen, please contact Raycus. Instruction: Occurs when the InterLock connection is open. Interlock Solutions: Error Short circuit the InterLock pins (Pin “ITL_A”...
-
Page 44: Warranty, Repair And Return
Raycus has the right to selectively repair or replace any product that has a material or technical problem during the warranty period. All products repaired or replaced during the warranty period only provide free warranty services for products with special problems. -
Page 45: Service And Repair
All service and maintenance shall be performed by qualified Raycus personnel. Please contact Raycus as soon as possible when problems under warranty about maintenance happened to the product. The product returned with permission should be placed in a suitable container.
