This section lists the S5200F-ON Series switch specifications.
CAUTION: Operate the product at an ambient temperature not higher than 45°C
(113°F).
CAUTION: Lithium Battery Caution: There is a danger of explosion if the battery is
incorrectly replaced. Replace only with same or equivalent type of battery. Dispose
of the batteries according to the manufacturer's instructions.
NOTE: For RoHS information, see

Chassis physical design

Table 1. Chassis physical design
Parameter
Height
Width

Specifications

Restricted Material Compliance.
Specifications
S5232F-ON: 1.72 inches (43.6 mm)
S5248F-ON: 1.72 inches (43.6 mm)
S5296F-ON: 3.42 (87 mm)
S5224F-ON: 1.72 inches (43.6 mm)
S5212F-ON: 1.72 inches (43.6 mm)
S5232F-ON: 17.1 inches (434 mm)
S5248F-ON: 17.1 inches (434 mm)
S5296F-ON: 16.6 inches (422 mm)
S5224F-ON: 17.1 inches (434 mm)
