11 Annex; Warning Messages; Fault Messages - BONFIGLIOLI ACTIVE Manual

11 Annex

11.1
The various control functions and methods and the hardware of the frequency inverter
contain functions that continuously monitor the application. In addition ones to the
messages documented in the manual the following fault messages are activated by
the CANopen communication module CM-CAN.
The warning reports are given via the parameter
to the following scheme.
Bit no. Warning code
Note:
11.2
The fault code that is stored after an fault occurs is made up of fault group FXX (high
Byte, hexadecimal) and the following code number XX (low Byte, hexadecimal).
F20
F23
Alongside the fault messages stated, there are further fault messages, however they
are only used for internal purposes and are not listed here. If you receive fault
messages which are not listed here, please contact us by phone.
46
46

Warning messages

0 0x0001 Warning Ixt
1 0x0002 Warning Short Term - Ixt
2 0x0004 Warning Long Term - Ixt
3 0x0008 Warning Heat sink Temperature Tc
4 0x0010 Warning Inside Temperature Ti
5 0x0020 Warning Limit
6 0x0040 Warning Init
7 0x0080 Warning Motor Temperature
8 0x0100 Warning Mains Failure
9 0x0200 Warning Motor Protective Switch
10 0x0400 Warning Fmax
11 0x0800 Warning Analog Input MFI1A
12 0x1000 Warning Analog Input A2
13 0x2000 Warning System bus
14 0x4000 Warning Udc
15 0x8000 Warning V-Belt
The meaning of the individual warnings are described in detail in the
operating instructions.

Fault messages

Code
21 CAN Bus-OFF
22 CAN Guarding
25 CAN Error-State
nn CAN Heartbeat failure - nn = node address of the failed subscriber
Warnings
Warning messages
Meaning
Communication fault
Meaning
270 bit-coded according
