12 Annex

12.1
The various control functions and methods and the hardware of the frequency inverter
contain functions that continuously monitor the application. In addition ones to the
messages documented in the manual the following fault messages are activated by
the Profibus-DP communication module CM-PDP.
The warning reports are given via the parameter
to the following scheme.
Note:
12.2
The fault code that is stored after an fault occurs is made up of fault group FXX (high
Byte, hexadecimal) and the following code number XX (low Byte, hexadecimal).
Alongside the fault messages stated, there are further fault messages, however they
are only used for internal purposes and are not listed here. If you receive fault mes-
sages which are not listed here, please contact us by phone.
38
38
Warning messages
Bit no. Warning code
0 0x0001
1 0x0002
2 0x0004
3 0x0008
4 0x0010
5 0x0020
6 0x0040
7 0x0080
8 0x0100
9 0x0200
10 0x0400
11 0x0800
12 0x1000
13 0x2000
14 0x4000
15 0x8000
The meaning of the individual warnings are described in detail in the op-
erating instructions.
Fault messages
Code
F20 61 Failure Profibus module
62 Profibus OFF (failure DP Master)
65 Profibus configuration fault
Warning messages
Warning Ixt
Warning Short Term - Ixt
Warning Long Term - Ixt
Warning Heat sink Temperature Tc
Warning Inside Temperature Ti
Warning Limit
Warning Init
Warning Motor Temperature
Warning Mains Failure
Warning Motor Protective Switch
Warning Fmax
Warning Analog Input MFI1A
Warning Analog Input A2
Warning System bus
Warning Udc
Warning V-Belt
Communication fault
Meaning
Warnings
270 bit-coded according
Meaning
