Section 1.2
Input Specifications
Input Description
Operating Temperature
Storage/Non-Operating
Temperature
Operating Humidity
Storage/Non-Operating Humidity
Vibration/Operating
Operating Shock
Storage/Non-Operating Shock
Pollution Level
Inputs per module
Input ranges
Input filters
RTD accuracy
100 Ω PT385, -200 ºC to 850 ºC
200 Ω PT385, -200 ºC to 850 ºC
500 Ω PT385, -200 ºC to 850 ºC
1000 Ω PT385, -200 ºC to 850 ºC
100 Ω PT3916, -200 ºC to 630 ºC
200 Ω PT3916, -200 ºC to 630 ºC
500 Ω PT3916, -200 ºC to 630 ºC
1000 Ω PT3916, -200 ºC to 630 ºC
100 Ω Ni618, -100 ºC to 260 ºC
120 Ω Ni672, -80 ºC to 260 ºC
10 Ω Cu 426, -100 ºC to 260 ºC
604 Ω NiFe 518, -100 ºC to 200 ºC
Resistance accuracy
0 to 150 Ω
The 2085-IR8-SC module has the following input specifications:
Table 1-1. Input/Performance/Environmental Requirements
-20 ºC to 65 ºC (-4 ºF to 149 ºF)
-40 ºC to 85 ºC (-40 ºF to 185 ºF)
5% to 95%, non-condensing
5% to 85%, non-condensing
10 Hz to 500 Hz, 2 G, 0.030 max peak-to-peak
25 G, peak acceleration, 11±1 ms pulse, half sine
25 G peak acceleration, 11±1 ms pulse, half sine; 35 G for
panel mount.
Meets Pollution Degree 2 requirements.
Eight 2-wire, 3-wire, or 4-wire resistance, or RTD
differential input channels
RTD:
100 Ω, 200 Ω, 500 Ω and 1000 Ω PT385 and Pt3916,
10 0Ω Ni618, 120 Ω Ni672, 10 Ω Cu 426, 604 Ω NiFe 518
Resistance:
0-150 Ω, 0-500 Ω, 0-1000 Ω, 0-3000 Ω
4 Hz, 17 Hz, 60 Hz, 470 Hz
Error at 25 C Max
Error at 25 °C, (Ohms)
Max
Chapter 1: Module Overview
Value
Error over -20 C to 65 C Max
±0.6
±0.5
±0.5
±0.5
±0.6
±0.5
±0.5
±0.5
±0.4
±0.3
±3.6
±0.3
Error over -20 °C to 65 °C,
(Ohms) Max
±0.2
User's Manual Pub. 0300321-01 Rev. A
1-3
±0.9
±0.8
±0.7
±0.7
±0.8
±0.7
±0.6
±0.6
±0.4
±0.4
±4.0
±0.4
±0.3
