Section 2.1
Compliance to
European
Union Directives
Section 2.2
Power
Requirements
WARNING
Chapter 2
Installation and Wiring
This chapter will cover:
•
Compliance to European union directives
•
Power requirements
•
General considerations
•
Installing the module
•
Field wiring connections
This product is approved for installation within the European Union and EEA
regions. It has been designed and tested to meet the following directives.

2.1.1 EMC Directive

The 2085-IR8-SC is tested to meet Council Directive 2014/30/EU
Electromagnetic Compatibility (EMC) and the following standards, in whole or
in part, documented in a technical construction file:
•
IEC 61000-6-4 Electromagnetic compatibility (EMC)–Part 6-4: Generic
standards–Emission standard for industrial environments
•
IEC 61000-6-2 Electromagnetic compatibility (EMC)–Part 6-2: Generic
standards–Immunity for industrial environments
•
EN 61131-2 Programable controllers - Part 2: Equipment requirements
and tests
The backplane power and the analog inputs of the device shall only be
supplied by an Isolated Secondary Limited Energy Low Voltage source.
The module receives power through the bus interface from the +5 VDC/+24
VDC system power supply, and a 24 VDC field power supply. Both must be
present for the module to operate.
Current rating at + 5 V is 94 mA maximum; for +24 V it is 15 mA maximum.
