Chapter 3: Configuring the Micro800 Expansion I/O 2085-IR8-SC Using CCW
Status &
Word
Reading
Index
Indication
15
Ch0 Data AI_00 Signed INT
Ch1 Data AI_01 Signed INT
Ch2 Data AI_02 Signed INT
Ch3 Data AI_03 Signed INT
Ch4 Data AI_04 Signed INT
Ch5 Data AI_05 Signed INT
Ch6 Data AI_06 Signed INT
Ch7 Data AI_07 Signed INT
Ch 1 & 0
AI_08 -
Status
Ch 3 & 2
AI_09 -
Status
Ch 5 & 4
AI_10 -
Status

3.5.9 Input Table

The input table size for the module is 16 words. Each channel data is assigned to
a signed 16-bit data byte and displays value between -32768 to +32767. The
actual display value is clamped by each Input Type limit, or by the signed 16-bit
data byte, whichever comes first. Other status indication bits, fault bits, and
software revision information are in an unsigned 16-bit Data Type.
Word
Index
AI_00
AI_01
AI_02
AI_03
AI_04
AI_05
AI_06
AI_07
AI_08
AI_09
AI_10
AI_11
AI_12
AI_13

3.5.10 Input Bit and Value Allocation

High Byte
14 13 12 11
OC OR UR PAH PAL
OC OR UR PAH PAL
OC OR UR PAH PAL
Tag Name for
2085-IR8-SC (14 Words)
Ch0 Data
Ch1 Data
Ch2 Data
Ch3 Data
Ch4 Data
Ch5 Data
Ch6 Data
Ch7 Data
Ch1 Status Ch 0 Status
Ch3 Status Ch 2 Status
Ch5 Status Ch 4 Status
Ch7 Status Ch 6 Status
Module Status
Software Revision
Bits
10 9 8 7
ADC FT1 -
ADC FT3 -
ADC FT5 -
User's Manual Pub. 0300321-01 Rev. A
Low Byte
6 5 4 3
OC OR UR PAH PAL ADC
OC OR UR PAH PAL ADC
OC OR UR PAH PAL ADC
3-15
2 1 0
FT0
FT2
FT4
