Chapter 3: Configuring the Micro800 Expansion I/O 2085-IR8-SC Using CCW
Input Type
EUx1
RTD
1 decimal point (DP)
2 DP for 150 Ω
1 DP for 500/1 K/3 K Ω
Resistance
Input Type
Input Value
RTD
850.00 °C
100 Ω
850.00 °C
Pt
-200.00 °C
0.385
-200.00 °C
200 Ω
850.00 °C
The defined, data display resolution for each input type is listed in the following
table. If the Data Format of the Input Type supports the resolution up to after the
decimal point, the fractional part of the input reading is shifted up to display in
integers:
In Engineering Unit ×10 format, the valid display range is from -200 to 850 in
integers. The Raw/Proportional format provides 65 K resolution based on the
valid range in EU×1 format of the selected Input Type. The same scaling
requirement applies to the Percentage format, which has 10 K resolution.
Index
Selection
Pt 385 100 Ω
0
Pt 385 200 Ω
1
Pt 385 500 Ω
2
Pt 385 1000 Ω
3
Pt 3916 100 Ω
4
Pt 3916 200 Ω
5
Pt 3916 500 Ω
6
Pt 3916 1000 Ω
7
Cu 426 10 Ω
8
Ni 618 100 Ω
9
Ni 672 120 Ω
10
NiFe 518 604 Ω
11
150 Ω
12
500 Ω
13
1000 Ω
14
3000 Ω
15
Range points and limits for Input Types are provided in the following table. For
each Input Type, the limits are set to the maximum and minimum values of its
range:
Condition
High Limit
High Range
Low Range
Low Limit
High Limit
EUx10
Integer
1 DP for 150 Ω
Integer for 500/1 K/3 K
Ω
Note
Default
EU x1
EU x10
8500
850
8500
850
-2000
-200
-2000
-200
8500
850
User's Manual Pub. 0300321-01 Rev. A
Raw Prop
Percentage
10 K
56K
10.5 K
Raw Prop Percentage
32767
10000
32767
10000
-32768
0
-32768
0
32767
10000
3-19
