3-12 Chapter 3: Configuring the Micro800 Expansion I/O 2085-IR8-SC Using CCW
Section 3.5
Software Information
User's Manual Pub. 0300321-01 Rev. A

3.5.1 Software Versioning

The software version tracks major and minor revisions for end users.
The shipped software version begins at version 1.1.
Once released, the major revision is typically incremented if new features are
introduced to the product. Otherwise only the minor revision is incremented.

3.5.2 Software Updates

In-field updating of the software by the end user is not supported.

3.5.3 Startup and Factory Default Conditions

After the module boots and before the initial configuration is received, the
module holds the default configuration as specified in the Configuration
Assembly. There is no input data communication and no signal outputting before
the controller goes into run mode. The default configuration is for all channels
enabled in the 3-wire, 100PT385 range with the 17 Hz filter in Engineering ×1
units.

3.5.4 PLC Interfaces

The 2085 platform treats all data on an I/O module as a member of a named
Array of Words.
Module Identity
The following values will be stored in the Vendor ID, Product_Type,
Product_Code, Series_Rev, and Mod_Features arrays:
Parameter
Vendor ID
Product Type
Product Code
Series Rev
Module Catalog String

3.5.5 Connection Types and Assembly Sizes

The size of each assembly is listed in the table below. Each word takes 2 bytes.
These values are stored in the Mod_Size array:
Table
Configuration Assembly
Input Assembly
Output Assembly
Description
58 (Spectrum Controls) [0×03A]
10 (Analog) [0×0A]
119 [0×77]
50208 [0×C420] (First release revision
is 1.1)
2085-IR8-SC
Size (words)
32
14
1
