Chapter 3: Configuring the Micro800 Expansion I/O 2085-IR8-SC Using CCW
Section 3.3
2085-IR8-SC
Tab on CCW
Before you start, if needed, install the latest version of Rockwell Automation's
Connected Components Workbench (CCW) Standard Edition.
NOTE
To add the module to your project, and see its configuration parameters on the
CCW configuration tab:
Using the Module Profile Tool to import the 2085-IR8 AOP into CCW
software is necessary only if you are using a CCW version earlier than
11.00.00. For information on manually importing an AOP file, see
Appendix A. For Version 11.00.00 and later, the module is already
available as a selection from the CCW Expansion Modules drop-down
menu:
7. From your CCW project, load the module AOP to a first Available slot
from the Expansion Modules drop-down list.
8. Once the module AOP is loaded, to view the associated variables, click
the Module Catalog Name option.
User's Manual Pub. 0300321-01 Rev. A
3-5
