10. Technical data

10. Technical data

10.1 MDU micro-metering unit

Designation
Temperature range
Mounting position
Dimensions (WxLxD)
Number of lubricant
outlets
Volumetric oil flow per
outlet
Operating voltage for
control unit
Electrical connection
Protection class
Working temperature
Operating viscosity
Electrical data
Rated operating voltage
Enable input
Error signal output
Technical data, Table 4
-10°C to +70°C
Any
105 x 60 x 45 mm
4, individually
adjustable
0.5–5 mm³/min
24 VDC
M12x1
IP67
10–50 °C
20 -500 mm²/s
24 VDC
0/24 VDC
0 VDC = error,
24 VDC = no error

10.2 MDR lubricant reservoir

Designation
Dimensions (WxLxH)
Contents
Working temperature
Fill level monitor in reservoir
Compressed air supply
Oil pressure (pressure on lubricant)
Operating viscosity
Pressure regulating valve, set to
Weight (empty)
EN
Page 61
Technical data, Table 5
110 x 313 x 360 mm
1 liter
+ 10 to +50 °C
24 V DC
4.5 to 10 bar
4 bar
20–500 mm²/s
16 bar
6 kg
