Environmental

• Size (H x W x D):
–
–
–
–
• Weight:
–
–
–
–
• Stainless steel grade 304L
• IP rating: IP 65
• Temperature range: –20 to +60 °C (–4 to +140 °F)
• Stainless steel cabinet optional
• Measurement category II
• Pollution degree 2
• Maximum altitude: 2 000 m (6 561.7 ft.)

Power Supply

• 100 to 240 VAC, 47 to 63 Hz
• Power consumption:
–
–
SKF Multilog On-Line System IMx-S
User Manual
Standard cabinet:
IMx-S 16: 500 × 400 × 155 mm (19.7 x 15.7 x 6.1 in.)
IMx-S 32: 500 × 500 × 220 mm (19.7 x 19.7 x 8.7 in.)
Stainless steel cabinet:
IMx-S 16: 500 × 400 × 210 mm (19.7 x 15.7 x 8.3 in.)
IMx-S 32: 500 × 500 × 220 mm (19.7 x 19.7 x 8.7 in.)
Standard cabinet:
IMx-S 16: 15,0 kg (33.1 lb.)
IMx-S 32: 21,0 kg (46.3 lb.)
Stainless steel cabinet:
IMx-S 16: 21,5 kg (47.4 lb.)
IMx-S 32: 23,1 kg (50.9 lb.)
IMx-S 16: 30 W
IMx-S 32: 60 W
