Page 62

11. Accessories

1
2
3 4
5 6
7 8
9 10
Item Designation
MDU
1 Mounting rail
2 Cable socket M12x1, straight
Cable socket M12x1, straight with cable 5 m
3 1/16" adapter, plastic
(see page 29, item 5)
4 1/16" ferrule (sleeve) and clamp ring
5 Tube 1/16", 5 m
Tube 1/16", 25 m
6
1/16" tube cutter
7
MDR
8 Filling pump, complete
9 Coupling socket (for filler coupling)
Plastic tube (main lubricant line)
10
Accessories for connection side (spindle)
11 Socket union 1/4" for tube Ø1/16", brass
Socket union M6 for tube Ø1/16", brass
12 Adapter M5 to 1/4"-28UNF, brass
1) Order No. 169-510-018 is always required for this material and must be ordered separately.
)
1
)
1
)
1
11. Accessories
Accessories
Order No.
886-570-005
179-990-371
179-990-600
169-510-017
169-510-018
167-002-010
167-002-011
169-000-335
169-000-262
995-001-500
WVN716-Ro6x1.25
857-120-002
857-120-001
847-120-001
