Defining the cycle times:
See Table C
The time the MDU requires for all outlets to
deliver lubricant once is referred to as the cy-
cle time. It is 8 seconds and also the shortest
ON-time. If the enable signal is set to ON, the
lubrication cycle always starts at outlet 1. If
the enable signal is set to OFF, the ongoing
cycle always ends at outlet 4. A cycle that has
been started is always performed completely,
i.e., all outlets deliver lubricant once, even if
the enable cycle has been set to OFF before
the cycle time (8 seconds) ends.
Cycle times as listed in Table C can be used for
external adjustment of the volumetric flow.
Cycle times for reducing volumetric flow via the enable signal
Cycle times for enable signal
[seconds]
ON
-
OFF
-
ON
-
OFF
-
0
-
8
8
-
8
-
4
-
8
-
8
-
8
-
8
-
Effective volumetric flow
as a percentage of set
volumetric flow
-
...
0
-
...
100%
67%
4
-
...
50%
8
-
...
6. Operation
Table C
see
Fig.
[%]
8
10
9
