Assembly instructions
4.3

MDR lubricant reservoir

The lubricant reservoir should be installed in a
freely accessible area to allow for manual fill-
ing and visibility of both sight glasses (fill level
minimum and fill level maximum).
It must be ensured that there is still enough
clearance above the reservoir for venting and
connection of the electrical fill level switch.
The lubricant reservoir is mounted in a verti-
cal position, with the connection for lubrication
lines and filler nozzle located in the lower part
of the reservoir. The lubricant outlet and filler
coupling can be interchanged.
Danger!
The pressure regulating valve on the
side of the reservoir is non-adjustable
and cannot be modified or removed.
The compressed air supply to be connected
generates priming pressure for the lubricant.
Lubricant and compressed air are separated
from each other by a dividing piston, so a
compressed air filter is not required.
Any assembly holes must be made according
to the diagram on the following page.
During assembly and especially when drilling,
always pay attention to the following:
o Maintain safety clearances and comply with
local regulations for assembly and accident
prevention.
o The MDR lubricant reservoir may only be
installed vertically.
o The MDR lubricant reservoir must be
installed an adequate distance from sources
of heat.
o Existing supply lines must not be damaged
by assembly work.
Page 21
o Other units must not be damaged by
assembly work.
o The MDR lubricant reservoir must not be
installed within range of moving parts.
Contents of the supplied accessories kit:
o Hexagon head screws (4x) acc. to
ISO 4014-M8x130-8.8
o Washers (4x) acc. to
ISO 7090- 8-200-HV
o Hexagon nuts (4x) acc. to
ISO 4032-M8-8
o Two-tube socket wrench WAF 10x13
o Vent hose, transparent and highly flexible,
60 cm long
