Assembly instructions
4.6
Note on the rating plate
The rating plate of the MDU micro-metering
unit and the MDR lubricant reservoir provides
important key data such as type designation
and serial number (or customer number).
To avoid loss of this data in case a rating plate
becomes illegible, these characteristics should
be entered in the following table.
• Enter key data from rating plate in the
following table.
Page 33
4.6.1 MDU rating plate
SKF Lubrication Systems Germany GmbH
Type designation
Serial number
4.6.2 MDR rating plate
SKF Lubrication Systems Germany GmbH
Type designation
MDRX-X X X X + X X X
P max. X X bar
Serial number
EN
