Chapter 2
Installing the Cisco ONS 15501

Setting Up Alarm Contacts

To set up alarm contacts, follow these steps:
Obtain an 8-conductor, 8 AWG solid-wire cable and terminate one end with an RJ-45 connector.
Step 1
Connect the stub end of the alarm cable to the alarm system contacts, either to miscellaneous discrete
Step 2
inputs on terminal equipment or to a central office alarm panel.
Connect the RJ-45 connector to the Cisco ONS 15501.
Step 3
See
Definitions" section on page

Installation Commands

You can connect to a Cisco ONS 15501 locally using a serial connection or remotely through SNMP. See
the
"Configuring Local Serial Communication" section on page 3-1
of these options. After you establish a connection, use the following commands to complete the hardware
installation. See

Introductory Commands

You can use the following commands to establish communication with the Cisco ONS 15501 and to
access additional information about the amplifier.

Review and Operational Commands

You can use the following commands to review the overall status of the Cisco ONS 15501.
78-14134-01, Release 1.0
2 2 F e b r u a r y 2 0 0 2
the"Alarm Contact Closures" section on page 3-4
1-8.
Chapter 4, "Command Reference,"
help — Displays a list of all available commands
sys-info — Displays the basic information on the system, including CLEI (Common Language
Equipment Identifier) code, model number, serial number, MAC address, firmware version,
firmware build date, and firmware update date
alarm — Displays a list of alarms in the system
status — Displays the measured, alarm mean, and alarm trigger values for input power, internal case
temperature, optical gain, and output signal power, as well as the measured values for optical output
power and output attenuation
and the
"Cisco ONS 15501 LED Alarm
for instructions on setting up either
for a complete list of available commands.
Cisco ONS 15501 User Guide
Installation Commands
2-7
