MICRO-EPSILON C-Box/2A Operating Instructions Manual page 51

Operation
Digital input
Fields with a grey
background re-
quire a selection.
Dark bordered
fields require the
Value
specification of a
value.
C-Box/2A
Function Disabled
Master C-Box value
Forward to sensor 1
Forward to sensor 2
Forward to sensor 1 and 2
Logic for digital Low-level logic
input
High-level logic
The multifunctional
input has no function.
The multifunctional
input is master
impulse input for the
C-Box.
The multifunctional
input is forwarded to
the corresponding
input of connected
sensor 1.
The multifunctional
input is forwarded to
the corresponding
input of connected
sensor 2.
The multifunctional
input is forwarded to
the corresponding
inputs of connected
sensors 1 and 2.
