MICRO-EPSILON C-Box/2A Operating Instructions Manual page 12

Functional Principle, Technical Data
Model
Analog output
Laser switch off
Firmware
LED
Power supply
Power consumption
sensors
Weight
C-Box/2A
C-Box/2A
- 1 current output per connected sensor
ƒ 4 – 20 mA
- 1 voltage output per connected sensor; programmable:
ƒ Unipolar 0 – 5 V / Unipolar 0 – 10 V
ƒ Bipolar ± 5 V / Bipolar ± 10 V
- Tolerance of current and voltage output: 0.04 %
- Switch respectively voltage input:
ƒ switching input connected with
ƒ switching input open
ƒ input voltage < 3 V (HTL)
ƒ input voltage > 8 V (HTL)
Measurement configurations can be saved (max. 8)
two languages (English, German), can be updated
for successful connection controller/sensor, Ethernet
- 13 – 30 VDC for full functionality, power consumption max. 200 mA without sensor
- 10 – 13 VDC with reduced DA converter function, power consumption max. 200 mA
without sensor, analog output 0 - 5 V or ± 5 V only
- Reverse polarity protection
- No galvanic isolation, all GND signals are connected internally and with the hous-
ing
maximum two sensors from internal power supply
appr. 210 g
> laser = on
> laser = off
> laser = on
> laser = off
