Functional Principle, Technical Data
2.2
Model
Connections
Supported sensors
Functions
C-Box/2A

Technical Data

C-Box/2A
- 2 Sensor connectors (HD-Sub, 15-pin),
- 2 RS422 interfaces
- 1x Ethernet (PC, 100 Mbit/s),
- 1x USB 2.0, type B, max. 12 Mbit,
- 1 plug-in terminal block 16-pin
ƒ External power supply
ƒ External laser on/off
ƒ External trigger input
ƒ 2 analog outputs (current or voltage)
- 1 external multi function input
- 1 external trigger input, HTL and TTL compatible (measurement output, edge)
- Input voltage
ƒ TTL ≤ 0.7 V / HTL ≤ 3.0 V
ƒ TTL > 2.2 V / HTL > 8.0 V
- input current 3.0 mA max.
- input frequency 100 kHz max.
- 2 switching outputs
Sensors of the ILD 1420 series with a measuring rate of 0.25 ... 4 kHz, sensors of the
ILD 1750 series with a measuring rate of 0.3 ... 7.5 kHz and sensors of the ILD 2300
series with a measuring rate of 1.5 ... 49 kHz
Filter: average moving 2...512 / recursive 2...32768, Median 3,5,7,9
Zero, mastering, synchronization
Scaling analog outputs
> trigger not active
> trigger active
